Catalog PDN1000-3US Actuator Products – Rodless Cylinders
Parker Pneumatic P1X Series

16 to 25 mm bore sizes

L + STROKE

SK SC SD SD SC
B SR SG SG
ST
SH C SP

SE SF
SQ

SM SJ SJ
Actuator Products
Rodless Cylinders
Bore SG SH
(mm) SC SD SE SF Max Min in-lbs SJ SK SP SQ SR ST C L
0.71 0.16 1.65 1.38 0.57 0.18 0.98 1.93 1.34 0.24 0.16 1.46 5.87
16 26 M3
(18) (4) (42) (35) (14.5) (4.5) (25) (49) (34) (6) (4) (37) (149)
0.89 0.14 1.89 1.57 0.57 0.18 1.54 2.24 1.50 0.32 0.20 1.65 6.65
20 61 M4
(22.5) (3.5) (48) (40) (14.5) (4.5) (39) (57) (38) (8) (5) (42) (169)
Series
0.79 0.10 2.46 2.03 0.57 0.18 1.97 3.03 1.97 0.47 0.39 2.09 7.48
OSP-P
25 (20) (2.5) (62.5) (51.5) (14.5) (4.5) 104 (50) (77) M6 (50) (12) (10) (53) (190)
inches (mm)
SH = max. energy absorption
P1X
Series
32 to 63 mm bore sizes
L + STROKE
SK SG SG
P1Z
Series
SR SC SC
ST
SD SD
C SP
SM
GDL
Series
SE
SF SQ
SJ SJ
Bore SG SH
(mm) SC SD SE SF Max Min in-lbs SJ SK SP SQ SR ST C L
0.87 0.28 2.62 2.19 1.06 0.67 2.56 3.86 2.11 0.55 0.47 2.24 8.90
32 226 M8
(22) (7) (66.5) (55.5) (27) (17) (65) (98) (53.5) (14) (12) (57) (226)
1.26 0.28 3.09 2.58 1.34 0.94 2.56 4.41 2.50 0.67 0.47 2.64 9.61
40 (32) (7) (78.5) (65.5) (34) (24) 608 (65) (112) M10 (63.5) (17) (12) (67) (244)
1.50 0.32 3.90 3.15 2.17 1.77 2.76 5.35 3.05 0.87 0.67 3.23 10.16
50 1042 M12
(38) (8) (99) (80) (55) (45) (70) (136) (77.5) (22) (17) (82) (258)
1.50 0.32 4.41 3.68 1.73 1.34 2.76 6.22 3.50 0.98 0.79 3.74 11.65
63 1042 M16
(38) (8) (112) (93.5) (44) (34) (70) (158) (89) (25) (20) (95) (296)
inches (mm)
SH = max. energy absorption
