Page 241 - Parker - Parker Pneumatic

Catalog PDN1000-3US Actuator Products – Rodless Cylinders
Parker Pneumatic P1X Series

intermediate support brackets

end mount

CE

CA CD 4 - ØCH CF
CB CG
CC

B

CE

CK

CJ
Actuator Products
Rodless Cylinders
intermediate support brackets (2 per kit)
Bore
(mm) CA CB CC CD CE CF CG CH
16 1.654 2.205 2.52 0.118 0.472 0.787 1.378 0.157
Series
(42) (56) (64) (3) (12) (20) (35) (4)
OSP-P
1.929 2.52 2.953 0.157 0.551 0.787 1.496 0.197
20
(49) (64) (75) (4) (14) (20) (38) (5)
2.362 2.992 3.465 0.236 0.768 0.787 1.575 0.276
25 (60) (76) (88) (6) (19.5) (20) (40) (7)
P1X
Series
2.913 3.465 3.937 0.236 0.846 0.787 1.575 0.276
32
(74) (88) (100) (6) (21.5) (20) (40) (7)
3.543 4.252 4.882 0.236 0.965 1.181 2.362 0.354
40
(90) (108) (124) (6) (24.5) (30) (60) (9)
4.173 4.882 5.512 0.315 1.201 1.181 2.362 0.354
P1Z
Series
50 (106) (124) (140) (8) (30.5) (30) (60) (9)
5.118 5.984 6.772 0.394 1.516 1.969 3.543 0.433
63
(130) (152) (172) (10) (38.5) (50) (90) (11)
GDL
Bore Kit part number
Series
(mm) CJ CK End mount or no mount Bottom mount
0.236 0.709
16 l080180016 l080190016
(6) (18)
0.315 0.866
20 l080180020 l080190020
(8) (22)
0.394 1.161
25 l080180025 l080190025
(10) (29.5)
0.394 1.24
32 (10) (31.5) l080180032 l080190032
40 — — l080180040
50 — — l080180050
63 — — l080180063
inches (mm)
