Catalog PDN1000-3US Actuator Products – Rodless Cylinders
Parker Pneumatic P1Z Series - Basic Version

Mountings

Flanges Only on 4xØFD
Ø 16 mm
FZ 2xF
FY FZ

FX FX T LS + STROKE T
FW FW

Ø F ØFD FW FX FY FZ T LS Order code
16 5.2 – 42 33 – 20 2.3 92 PDC15-FH
(0.09)
(0.20)
(1.30)
(0.79)
(1.65)
(3.62)
B 20 – 6 52 40 20 32 3 115 PK1a20-FH
(2.05)
(1.57)
(0.78)
(1.26)
(0.12)
(4.53)
(0.24)
32 – 7 80 64 28 44 5 133 PK1a25-FH
(0.28) (3.15) (2.52) (1.10) (1.73) (0.20) (5.24)
Brackets Only on
Ø 16 mm
Actuator Products
Rodless Cylinders
LH
LH
LK LJ
t
2xLE L
Series
OSP-P
LY LX LY LX
P1X
Series
2xØLD LC
LF
LF LS + STROKE
L XL + STROKE
P1Z
Series

GDL
Series
LT + STROKE
XM + STROKE

Ø t L LC ØLD LE LF LH LJ LK LX LY LS LT XL XM Order code
2.3 14.8 8.8 5.2 6 14 16 -2 33 42 109.6 79 121.6 96.6
16 (0.09) (0.58) (0.35) – (0.20) (0.24) (0.55) (0.63) (-0.08) (1.30) (1.65) (4.32) (3.11) (4.79) (3.80) PDC15-lB*

20 3 28 18 6.2 – 10 23 19 4 30 43 151 85 171 121 PK1a20-lB*
(0.12) (1.10) (0.71) (0.24) (0.39) (0.91) (0.75) (0.16) (1.18) (1.69) (5.94) (3.35) (6.73) (4.76)
3 35 23 7 12 30 30 0 46 62 179 203
32 (0.12) (1.38) (0.91) (0.28) – (0.47) (1.18) (1.18) (0) (1.81) (2.44) (7.05) ** (7.99) ** PK1a25-lB*
* Set of 2 pcs
** Impossible mounting
