Types of Assembly
1-Conductor/1-Pin Carrier Terminal Blocks and 6
1-/2-Conductor Female Plugs 305
51,4 5,5
28,5
Pin cover
with receptacle for miniature WSB
29,5
52,4
Carrier terminal block
6
83,5
30
28,5
38,2
71,4
1-conductor female plug Carrier terminal block with shield contact
Commoning carrier terminal blocks via 280 and 780 Series jumpers and testing
using 280-4.. test plug adapter.
52,8
28,5 2,5
45,2
2-conductor female plug Ground carrier terminal block
Carrier terminal blocks can only be commoned via 280 Series adjacent and alternate
jumpers.
