X-COM -SYSTEM
®
6 2-Pin Carrier Terminal Blocks
306

500 V/6 kV/3 1 300 V, 20 AU
I N 32 A 2 300 V, 20 A2
Terminal block width 5 mm / 0.197 in Terminal block width 5 mm / 0.197 in

1 500 V = rated voltage
6 kV = rated surge voltage
3 = pollution degree
250 V/4 kV/3 =
ominal voltage with shield contact
<_ 28,5 mm/ _> 1.12 in <_ 28,5 mm/ _> 1.12 in 2 See current-carrying capacity curve, page 360 and at
(also see Section 14)
www.wago.com
3 See application notes for:
Test plug modules, pages 289 – 290
( 29,5 mm/1.16 in ) ( 29,5 mm/1.16 in ) Staggered jumper, page 295
<____ 52,5 mm/2.07 in _____> <____ 52,5 mm/2.07 in _____> Push-in type wire jumper, page 295
Pack. Pack. Accessories
Item No. Item No.
Unit Unit
2-pin carrier terminal block, 2-pin ground carrier terminal block,
for DIN 35 rail, acc. to EN 60715 for DIN 35 rail, acc. to EN 60715
gray 769-156 100 green-yellow 769-227 100 Screwless end stop,
for DIN 35 rail,
2-pin carrier terminal block with shield contact, (no 6 mm wide
picture), for DIN 35 rail, acc. to EN 60715 gray 249-116 100 (4x25)
gray 769-221 1 50 Screwless end stop,
for DIN 35 rail,
10 mm wide
gray 249-117 50 (2x25)
769 Series Accessories Miniature WSB Quick marking system,
Appropriate marking system: 10 strips with 10 markers per card,
Miniature WSB (see Section 13) 5 mm wide markers 5
248-501
plain
End and intermediate plate, 1.1 mm thick Test plug module, Miniature WSB Quick marking system, plain,
orange 769-306 100 (4x25) 3 can be snapped together, 10 strips with 10 markers per card,
gray 769-305 100 (4x25) 5 mm wide 5 mm wide markers
gray 280-418 100 (4x25) yellow 248-501/000-002
Coding pin, Spacer module, red 248-501/000-005
for coding female plugs can be snapped together, blue 248-501/000-006
orange 769-435 100 (4x25) 5 mm wide gray 248-501/000-007
gray 280-419 100 (4x25) orange 248-501/000-012
Adjacent jumper, insulated, Test plug, light green 248-501/000-017
I N = I N terminal block with 500 mm cable, green 248-501/000-023
gray 280-402 200 (8x25) 2.3 mm Ø violet 248-501/000-024
yellow 210-137 50 5
Alternate jumper, insulated, Test plug adapter, 5 mm wide,
I N = I N terminal block for terminal blocks 1.5 - 4 mm²,
gray 280-409 100 (4x25) for 210-137 test plug 2.3 mm Ø
gray 280-404 100 (4x25)
Staggered jumper, 1-conductor female plug,
3 insulated, straight
Spacing: 5 mm, gray 769-101 200
I N 24 A
from 1 to 2 780-452 100 (4x25) 1-conductor female plug,
from 1 to 3 780-453 100 (4x25) angled
from 1 to 4 780-454 100 (4x25) gray 769-101/022-000
from 1 to 5 780-455 50 (2x25) 200
from 1 to 6 780-456 50 (2x25) 2-conductor female plug
from 1 to 7 780-457 50 (2x25) gray 769-121 100
from 1 to 8 780-458 50 (2x25)
Push-in type wire jumper, Pin cover,
3 insulated, with receptacle for miniature WSB
I N 9 A, gray 769-438 100 (4x25)
wire size 0.75 mm² orange 769-439 100 (4x25)
L = 60 mm 249-125 10
L = 110 mm 249-126 10
L = 250 mm 249-127 10

Certification organizations can be found in the overview on pages 622 and 623.
