selos CLASSIC LINE
selos

DIN rail terminal blocks with screw connection, type 9700 A.. S35

DIN rail terminal blocks with screw
connection – selos classic
The selos classic series offers the highest-quality
connecting technology. Thanks to its unique clamping
body design, aluminum or copper wire connections are
long lasting and maintenance-free.
The product line includes feed-through and ground
blocks for wires up to 50 mm .
2

High-quality screw • Steel free clamping body
connection technology – Increased corrosion resistance
– Extruded clamping body, nickel-plated brass
• Low contact resistance
– Clamping body has similar physical and chemical
characteristics as the conductor
– One piece clamping body/current bar

Connection of The following always applies when connecting
aluminum wires aluminium wires in the selos classic line:
possible • After being stripped, the ends of the wires must be
cleaned with a brush and then coated with acid-free
grease to prevent further oxidation.
• The terminal should be tightened to approx. 20 %
higher torque than what is stated for the clamping
screw.
With this type of terminal, it is not necessary to retighten
the clamping screws.

Wide connection • Connection range 0.5 – 50 mm
2
range Solid, fine-stranded and stranded wires can be con-
nected to the terminal blocks of selos classic line
without ferrules, as all block sizes have wire protection.

Compact design • Save space on the rail
selos classic line offers higher density due to the wire
size and terminal block pitch:

Connection range Pitch
2,5 mm 2 5 mm
4 mm 2 6 mm
10 mm 2 8 mm
16 mm 2 10 mm
25 mm 2 12 mm
35 mm 2 16 mm
56 More accessories page 124 ff.
