Truckline

Torque wrench system 6000 CT

• Accuracy of the scale value (in actuating direction)
according to DIN EN ISO 6789:2003 (D)
• Ideally suitable for industrial climbers
• In the pocket - carry in your hand or on your back
(Art.-No. 4645 34 400 and Art.-No. 4645 34 800 in safe box)
• Can be dismounted using an unlocking tool
(except Art.-No. 4645 34 400 and Art.-No. 4645 34 800)
• With serial number and certificate

Technical Data
Art.-No. drive test range length tolerance division release force weight note
Nm mm ± % Nm kg
4645 34 400 3/4“ 100-400 803 2 2.5 580N at 400 Nm 5 one-part
4645 34 800 3/4“ 300-800 1280 2 2.5 685 N at 800 Nm 8.3 one-part
4645 34 1000 1 3/4“ 400-1000 1788 3 5 590 N at 1000 Nm 10 two-part
4645 1 1600 1“ 600-1600 2455 3 5 685 N at 1600 Nm 14 two-part
4645 1 2000 1“ 800-2000 3034 4 6 685 N at 2000 Nm 18 two-part
Article No. Article Description QTY
4645 34 400 3/4" TORQUE WRENCH 100-400NM 1
4645 34 800 3/4" TORQUE WRENCH 300-800NM 1
4645 34 1000 1 3/4" TORQUE WRENCH 400-1000NM 1
4645 1 1600 1" TORQUE WRENCH 500-1600NM 1
4645 1 2000 1" TORQUE WRENCH 500-2000NM 1

Torque Wrench with Ratchet

• High precision and accuracy of ±4 % relative to the actual setting
• Easy and accurate adjustment by turning the handle
• All wrenches with draw lead square heads are suitable for tightening
clockwise/anti-clockwise
• Acoustic and haptic perception of torque release point
• Plant manufacturer’s test certificate in accordance with DIN

Technical Data
Art.-No. Measuring range Nm Measuring range ft. Lb. Weight kg Length mm Comment
4645 34 110 – 550 82 – 410 4.0 845 Draw-lead square-head
4645 34 1000 300 – 1.000 225 – 740 5.8 1.750 Draw-lead square-head including extension
4645 1 500 – 1.500 370 – 1.150 6.7 2.070 Draw-lead square-head including extension
Article No. Article Description QTY
4645 34 3/4" TORQUE WRENCH 110-550NM 1
4645 34 1000 3/4" TORQUE WRENCH 300-1000NM 1
4645 1 1" TORQUE WRENCH 500-1500NM 1

Technical data subject to change.
