Page 932 - Icon Ridge Automotive & Truck Catalog

Truckline

Securing collar - tool

• makes it easier to remove the securing collars that are frequently
stuck on the inside of the wheel bearings
• gap for adjusting screw of 6.3 mm = 1/4” ratchet for maximum power
and quick removal
• suitable for cars, transport vehicles and trucks
• unique construction always ensures the correct angle of the pin, irre-
spective of the size of the securing collar
• very easy to change the pin
• 7-pieces
• 5-95 mm working diameter

2x 2.5 mm
2x 3.0 mm
2x 3.5 mm

Article No. Article Description QTY
4914 2867 SECURING COLLAR TOOL V2867 1
4914 2867 25 E-TIPS F. V2867 Ø2.5MM 4PCS 1
4914 2867 30 E-TIPS F. V2867 Ø3.0MM 4PCS 1
4914 2867 35 E-TIPS F. V2867 Ø3.5MM 4PCS 1
Snap ring pliers set Maxi

• with the set of pliers 4 different fuse tongs can be put together by
simply changing the tips
• work area:
- integral: 165-300 mm
- external: 165-300 mm

Article No. Article Description QTY
4076 500 SNAP RING PLIERS SET MAXI 1
4076 500 1 PAAR ERS.-SPITZEN 65MM GERADE 1
4076 500 2 PAAR ERS.-SPITZ. 100MM GEB.90° 1
Contents:
• 1 x basic device for inner rings , shank length 500 mm
• 1 x basic device for outer rings 500 mm
• 4 pairs of tips: 2 x Ø 3.6 mm straight 2 x Ø 3.6 mm 90°
Seeger Circlip Pliers Set with Ring Fixing

• With these pliers you can create 6 different circlip pliers by changing
the points
• Working range:
- Internal: 78 - 159 mm
- External: 89 - 159 mm

Article No. Article Description QTY
4076 90 SNAP RING PLIERS SET RINGFIX 1
4076 90 1 PAIR REPL.POINTS STRAIGHT 1
4076 90 2 PAIR REPL.POINTS 45° CURVED 1
4076 90 3 PAIR REPL.POINTS 90° CURVED 1
Contents:
• 1x basis tool for internal shafts, jaw length 400 mm
• 1x basis tool for external shafts, jaw length 400 mm
• 6 pairs of points: 3x Ø 2.75 mm: straight, 45°, angled 90° 3x Ø
3.00 mm: straight, 45°, angled 90°

Technical data subject to change.
Availability subject to country specific rules and regulations. www.iconridge.com Source: Theo Förch GmbH & Co. KG 932
