Truckline

Torque Replicator

• Robust tightening and releasing tool for high-tensile screw connecti-
ons
• A planetary gear triples the torque applied at the handle
• Enables an increased threefold torque in combination with a torque
wrench

Application:
• Construction machines, trucks, agricultural machines, service vehi-
cles etc.

Technical Data
Art. No. Drive Drive max. Nm max. Nm
Article No. Article Description QTY Input Output
4642 1 TORQUE REPLICATOR 1400N 1 4642 1 1/2” 3/4” 450 1,400
4642 2 TORQUE REPLICATOR 2700N 1 4642 2 3/4” 1” 900 2,700

Torque multiplier 3200 Nm

• transmission 1:56 using a planetary gear
• very easy to remove the wheel bolts
• ideal for mobile use, trucks, agriculture, tool kit of service vehicles,
buses and long distance vehicles

Article No. Article Description QTY Technical Data
4642 3 1 TORQUE REPLICATOR 3200N 1
transmission ratio: 1:56
Contents: max output torque: 3200 Nm
• 1 x torque multiplier 3200 Nm drive: 1” external 4-edge
• 1 x extension 210 mm output: 1” external 4-edge
• 1 x crank weight: 8.5 kg
• 1 x each power socket 1” SW 32/SW 33

Technical data subject to change.
