Installation

5. Installation

This manual only describes installation of the flux card itself; for details on the installation
of the GuardII+ Series 4208 Platform assembly, flux probes or shaft trigger, refer to the
appropriate User Manual for that component.
This installation procedure assumes that no other monitoring technologies are installed in
the GuardII+ monitor. Note that if there is another monitoring technology, this will not affect
the installation of the flux card, however care must be taken to make sure the card and cabling
for the other technology are not disturbed.
NOTE:
GuardII+ installation must be performed by qualified personnel according
to all applicable local regulations and standards.

Use the monitor only as specified by the operating instructions or the safety
protection of the monitor may be impaired.

NOTE:
The information provided represents a typical installation for a GuardII+
Flux card. Some installations may require custom work not described
here; if assistance is needed contact Iris Power LP Technical Support. For
installation of other monitoring technologies refer to the User Manual for
that technology.

5.1. Overview

The installation shall be performed according to this manual and applicable local codes
and standards.

For valid monitor operation, the GuardII+ should only be connected to Iris Power LP flux
probes or Iris Power LP approved equivalents.

IMPORTANT:
The main power source for the GuardII+ should NOT be a line on which
severe voltage dips or voltage drop-outs may occur. These may cause
problems for the monitor.

NOTE:
Remove the electronics from the enclosure before drilling conduit holes.
Refer to the GuardII+ Series 4208 Platform Manual for details.

Note:
GuardII+ makes use of fasteners that are intended to be operated by hand;
only use hand tools for thumb screws and other hand-fasteners. Over

tightening will cause damage to the monitor.
• All cable entries into the box should be located as specified in the GuardII+ Series
4208 Platform Manual.
