High-Performance Taps
Victory Spiral-Flute HSS-E Taps • Blind Holes
™

• WN44EG TiN + CrC/C

for aluminum.

Shank Tolerance
D inch tolerance
.141–.635 +0, -.0015
>.635–1.51 +0, -.0020
>1.51–2.01 +0, -.0030

„ GT82 • Machine Screw and Fractional • Form C Semi-Bottoming Chamfer • DIN Length ANSI Shank

• For Aluminum

first choice
alternate choice

grade WN44EG
WN44EG
TiN+CrC/C inch dimensions
number pitch diameter
order # catalog # D1 TPI L L3 L2 D of flutes limit
5690761 GT825010 2 - 56 1.77 .31 .71 .141 2 H2
5690762 GT825011 4 - 40 2.20 .31 .71 .141 2 H2
5690765 GT825012 5 - 40 2.20 .31 .71 .141 2 H2
5690766 GT825013 6 - 32 2.20 .35 .79 .141 2 H3
5690767 GT825014 8 - 32 2.48 .43 .83 .168 2 H3
5690768 GT825015 10 - 24 2.76 .47 .98 .194 2 H3
.98
5690769 GT825016 1/4 - 20 2.76 .47 1.18 .194 2 2 H3
10 - 32
High-Performance Taps 5690781 GT825018 5/16 - 18 3.15 .59 1.18 .255 2 2 2 2 H5
.59
H3
5690780 GT825017
3.15
.255
1/4 - 20
3.15
1/4 - 28
.255
5690782 GT825019
H3
.59
1.18
1/4 - 28
1.18
.255
3.15
.59
H4
5690783 GT825020
5690784 GT825021
3.54
.318
1.38
.59
H3
5690785 GT825022
.59
5/16 - 24
1.38
5690786 GT825023
3.54
.318
H3
5/16 - 24
1.38
3.54
H4
.59
.318
5690787 GT825024 5/16 - 18 3.54 .59 1.38 .318 2 2 2 H5
5690788 GT825025 3/8 - 16 3.94 .75 1.54 .381 2 H3
5690789 GT825026 3/8 - 16 3.94 .75 1.54 .381 2 H5
5690790 GT825027 3/8 - 24 3.94 .75 1.54 .381 2 H3
5690791 GT825028 3/8 - 24 3.94 .75 1.54 .381 2 H4
5690792 GT825029 7/16 - 14 3.94 .71 1.61 .323 3 H3
5690793 GT825030 7/16 - 14 3.94 .71 1.61 .323 3 H5
5690795 GT825031 7/16 - 20 3.94 .71 1.61 .323 3 H3
5690796 GT825032 7/16 - 20 3.94 .71 1.61 .323 3 H5
5690797 GT825033 1/2 - 13 4.33 .91 1.85 .367 3 H4
5690798 GT825034 1/2 - 13 4.33 .91 1.85 .367 3 H5
5690799 GT825035 1/2 - 20 4.33 .91 1.85 .367 3 H3
5690800 GT825036 1/2 - 20 4.33 .91 1.85 .367 3 H5
