High-Performance Taps
™
Victory Spiral-Flute HSS-E-PM Taps • Blind Holes

• WS30MG nitride for titanium
and titanium alloys.
• WS34MG TiN + CrC/C for titanium

and titanium alloys.

D
D1
L3
L2
L
Shank Tolerance
D inch tolerance h6
.118–.236 +0, -.0003
.236–.394 +0, -.0004
.394–.709 +0, -.0004
.709–1.181 +0, -.0005
1.181–1.969 +0, -.0006

„ GT62 • Form C Semi-Bottoming Chamfer • Metric ANSI • For Titanium and Titanium Alloys

first choice
alternate choice

WS30MG
WS34MG
grade WS34MG grade WS30MG
TiN+CrC/C Nitride inch dimensions
number pitch diameter
order # catalog # order # catalog # D1 size L L3 L2 D of flutes limit
5565220 GT625504 5565219 GT625503 M2,5 X 0,45 1.81 .50 .56 .141 3 D3
5565222 GT625506 5565221 GT625505 M3 X 0,5 1.94 .63 .75 .141 3 D3
5565224 GT625508 5565223 GT625507 M4 X 0,7 2.12 .32 .76 .168 3 D4
5565226 GT625510 5565225 GT625509 M5 X 0,8 2.37 .46 .91 .194 3 D4
5565228 GT625512 5565227 GT625511 M6 X 1 2.50 .46 1.00 .255 3 3 D5
High-Performance Taps 5565232 GT625516 5565231 GT625515 M10 X 1,25 2.70 .48 1.12 .318 3 3 3 3 D5
.52
M7 X 1
2.72
1.15
.318
D5
5565230 GT625514
5565229 GT625513
M8 X 1,25
1.26
.381
5565233 GT625517
D5
5565234 GT625518
.53
2.93
.381
5565236 GT625520
5565235 GT625519
2.93
.53
M10 X 1,5
D6
1.26
D6
5565238 GT625522
3.38
5565237 GT625521
.77
M12 X 1,75
1.74
.367
