High-Performance Taps
Victory Spiral-Flute HSS-E Taps • Blind Holes
™

• WN44EG TiN + CrC/C

for aluminum.

Shank Tolerance
D inch tolerance
.141–.635 +0, -.0015
>.635–1.51 +0, -.0020
>1.51–2.01 +0, -.0030

„ GT86 • Machine Screw and Fractional • Form C Semi-Bottoming Chamfer • DIN Length ANSI Shank

• For Aluminum

first choice
alternate choice

grade WN44EG
WN44EG
TiN+CrC/C inch dimensions
number pitch diameter
order # catalog # D1 TPI L L3 L2 D of flutes limit
5690817 GT865010 2 - 56 1.77 .31 .71 .141 3 H2
5690818 GT865011 4 - 40 2.20 .31 .71 .141 3 H2
5690819 GT865012 5 - 40 2.20 .31 .71 .141 3 H2
5690840 GT865013 6 - 32 2.20 .35 .79 .141 3 H3
5690841 GT865014 8 - 32 2.48 .43 .83 .168 3 H3
5690842 GT865015 1/4 - 20 2.76 .47 1.18 .194 3 3 3 H3
.98
10 - 24
.98
.194
10 - 32
.47
H3
2.76
5690843 GT865016
High-Performance Taps 5690845 GT865018 5/16 - 18 3.15 .59 1.18 .255 3 3 3 3 H5
.59
H3
5690844 GT865017
.255
3.15
1/4 - 20
1/4 - 28
H3
5690846 GT865019
.255
1.18
.59
3.15
3.15
.255
5690847 GT865020
.59
1.18
H4
1/4 - 28
1.38
.59
H3
.318
5690849 GT865021
3.54
5690850 GT865022
3.54
1.38
.318
H3
.59
5690851 GT865023 5/16 - 18 3.54 .59 1.38 .318 3 3 H5
5/16 - 24
5690852 GT865024 5/16 - 24 3.54 .59 1.38 .318 3 H4
5690853 GT865025 3/8 - 16 3.94 .75 1.54 .381 3 H3
5690854 GT865026 3/8 - 16 3.94 .75 1.54 .381 3 H5
5690855 GT865027 3/8 - 24 3.94 .75 1.54 .381 3 H3
5690856 GT865028 3/8 - 24 3.94 .75 1.54 .381 3 H4
5690857 GT865029 7/16 - 14 3.94 .71 1.61 .323 3 H3
5690858 GT865030 7/16 - 14 3.94 .71 1.61 .323 3 H5
5690859 GT865031 7/16 - 20 3.94 .71 1.61 .323 3 H3
5690860 GT865032 7/16 - 20 3.94 .71 1.61 .323 3 H5
5690861 GT865033 1/2 - 13 4.33 .91 1.85 .367 3 H4
5690862 GT865034 1/2 - 13 4.33 .91 1.85 .367 3 H5
5690863 GT865035 1/2 - 20 4.33 .91 1.85 .367 3 H3
5690864 GT865036 1/2 - 20 4.33 .91 1.85 .367 3 H5
