Page 7 - 2020 October Lighting Catalog
P. 7
PANELS / troffers
Color and Wattage Tunable Led Panels
0-10V
0-10V Dimmable
old
Order
New Cat. Size Color Watts volts Delivered Lm/w dimming Replaces In Case Each
Lumens
Cat. No. No. Temp Range @Max Watts Fluorescent Qty
3000K - 5000K CCT & Wattage Tunable DLC Standard
71174B - 1X4 3K 4K 5K 30w/35W/40W 120-277V 4,306 110 0-10V 64-128W 4
71164B 71164 2x2 3K 4K 5K 30w/35W/40W 120-277V 4,262 110 0-10V 64-128W 4
71165B 71165 2x4 3K 4K 5K 35W/40W/50W 120-277V 5,956 118 0-10V 64-128W 4
Accessories
71786A 15W Emergency Battery Backup (for use with 30w & 40w fixtures) 1
71787A 20w Emergency Backup (for use with 50W fixtures) 1
LED Troffers
0-10V
Cat. Color Delivered REPLACES Order
No. Size Temp Watts volts Lumens Lm/w CRI dimming Fluorescent In Case Each
Qty
2x2 DLC Standard
71788A 2x2 3000K 40W 120-277V 4,078 101 82 0-10V 64-128W 2
71789A 2x2 4000K 40W 120-277V 4,160 104 80 0-10V 64-128W 2
71790A 2x2 5000K 40W 120-277V 4,242 106 80 0-10V 64-128W 2
2X4 DLC standard
71791A 2x4 3000K 50W 120-277V 4,652 98 80 0-10V 128-216W 2
71792A 2x4 4000K 50W 120-277V 4,742 100 80 0-10V 128-216W 2
71793A 2x4 5000K 50W 120-277V 4,830 103 80 0-10V 128-216W 2 PMMA lens
class 2 isolated driiver
2x2 DLC Premium flicker free driver
71780A 2x2 3000K 30W 120-277V 4,088 136 80 0-10V 64-128W 2 0-10v dimmable
emergency backup
71781A 2x2 4000K 30W 120-277V 4,150 138 80 0-10V 64-128W 2
71782 2x2 5000K 30W 120-277V 5,200 125 82 0-10V 64-128W 2
2X4 DLC Premium
71783 2x4 3000K 40W 120-277V 5,715 130 83 0-10V 128-216W 2
71784A 2x4 4000K 40W 120-277V 5,080 127 82 0-10V 128-216W 2
71785 2x4 5000K 40W 120-277V 6,500 130 80 0-10V 128-216W 2
Accessories
71786A 15W Emergency Battery Backup (for use with 30w and 40w Troffers) 1
71787A 20W Emergency Battery Backup (for use with 50w Troffers) 1
Please review online specification sheets. Pictures and certifications may not be 100% representative of the product listed.
To view details of our DLC qualified products, please consult the DLC Qualified Products List at www.designlights.org/qpl
FOR MORE INFO SEE THE 2019 LIGHTING Catalog and or visit morrisproducts.com 5
