PISTON PINS PISTON PINS

Trend Pin Chart Trend Pin Chart
Part # OD Length Wall Thickness Gram Wt. Series Coated Note Part # OD Length Wall Thickness Gram Wt. Series Coated Note
(MM) (MM) (MM) (MM)
H9272950155 23,55 74,93 3,94 139,00 H SERIES - - H9902750135C 25,15 69,85 3,43 128,00 H SERIES - Chamfered
H9272950155C 23,55 74,93 3,94 139,00 H SERIES - Chamfered CA9902750140C 25,15 69,85 3,56 130,00 TP-1 SERIES - Chamfered
H9272950155D 23,55 74,93 3,94 139,00 H SERIES DLC Coated Pin - H9902750145 25,15 69,85 3,68 136,00 H SERIES - -
H9272950165 23,55 74,93 4,19 148,00 H SERIES - - H9902750145C 25,15 69,85 3,68 136,00 H SERIES - Chamfered
H9272950165C 23,55 74,93 4,19 148,00 H SERIES - Chamfered H9902750145D 25,15 69,85 3,68 136,00 H SERIES DLC Coated Pin -
H9272950165CD 23,55 74,93 4,19 148,00 H SERIES DLC Coated Pin Chamfered H9902750155 25,15 69,85 3,94 143,00 H SERIES - -
H9272950165D 23,55 74,93 4,19 148,00 H SERIES DLC Coated Pin - H9902750155C 25,15 69,85 3,94 143,00 H SERIES - Chamfered
H9272950175 23,55 74,93 4,45 155,00 H SERIES - - H9902750155CD 25,15 69,85 3,94 143,00 H SERIES DLC Coated Pin Chamfered
H9272950175C 23,55 74,93 4,45 155,00 H SERIES - Chamfered H9902750155D 25,15 69,85 3,94 143,00 H SERIES DLC Coated Pin -
H9272950175D 23,55 74,93 4,45 155,00 H SERIES DLC Coated Pin - H9902750165 25,15 69,85 4,19 150,00 H SERIES - -
G9272950185 23,55 74,93 4,70 162,00 G SERIES - - H9902750165C 25,15 69,85 4,19 150,00 H SERIES - Chamfered
H9272950185 23,55 74,93 4,70 161,00 H SERIES - - H9902750165CD 25,15 69,85 4,19 150,00 H SERIES DLC Coated Pin Chamfered
H9272950185C 23,55 74,93 4,70 161,00 H SERIES - Chamfered H9902750165D 25,15 69,85 4,19 150,00 H SERIES DLC Coated Pin -
H9272950185CD 23,55 74,93 4,70 161,00 H SERIES DLC Coated Pin Chamfered CA9902750175CD 25,15 69,85 4,45 157,00 TP-1 SERIES DLC Coated Pin Chamfered
H9272950185D 23,55 74,93 4,70 161,00 H SERIES DLC Coated Pin - CA9902750185CD 25,15 69,85 4,70 163,50 TP-1 SERIES DLC Coated Pin Chamfered
CA9272950200 23,55 74,93 5,08 172,80 TP-1 SERIES - - G9902750185 25,15 69,85 4,70 162,00 G SERIES - -
CA9272950200D 23,55 74,93 5,08 172,80 TP-1 SERIES DLC Coated Pin - H9902750185 25,15 69,85 4,70 164,00 H SERIES - -
H9272950205 23,55 74,93 5,21 174,00 H SERIES - - H9902750185C 25,15 69,85 4,70 164,00 H SERIES - Chamfered
H9272950205C 23,55 74,93 5,21 174,00 H SERIES - Chamfered H9902750185CD 25,15 69,85 4,70 164,00 H SERIES DLC Coated Pin Chamfered
H9272950205D 23,55 74,93 5,21 174,00 H SERIES DLC Coated Pin - H9902750185D 25,15 69,85 4,70 164,00 H SERIES DLC Coated Pin -
H9272950215 23,55 74,93 5,46 180,00 H SERIES - - H9902750195 25,15 69,85 4,95 170,00 H SERIES - -
H9272950215C 23,55 74,93 5,46 180,00 H SERIES - Chamfered H9902750195C 25,15 69,85 4,95 170,00 H SERIES - Chamfered
H9272950225 23,55 74,93 5,72 186,00 H SERIES - - CA9902750200 25,15 69,85 5,08 175,20 TP-1 SERIES - -
H9272950225C 23,55 74,93 5,72 186,00 H SERIES - Chamfered CA9902750200D 25,15 69,85 5,08 175,20 TP-1 SERIES DLC Coated Pin -
H9272950225CD 23,55 74,93 5,72 186,00 H SERIES DLC Coated Pin Chamfered CA9902750205T 25,15 69,85 5,21 162,60 TP-1 SERIES - Tapered
H9272950225D 23,55 74,93 5,72 186,00 H SERIES - - H9902750205 25,15 69,85 5,21 176,00 H SERIES - -
CA9273100225 23,55 78,74 5,72 196,10 TP-1 SERIES - - H9902750205C 25,15 69,85 5,21 176,00 H SERIES - Chamfered
CA9273100225D 23,55 78,74 5,72 196,10 TP-1 SERIES DLC Coated Pin - H9902750205CD 25,15 69,85 5,21 176,00 H SERIES DLC Coated Pin Chamfered
CA9273100250D 23,55 78,74 6,35 217,00 TP-1 SERIES DLC Coated Pin - H9902750220 25,15 69,85 5,59 186,00 H SERIES - -
CA9282125235CD 23,57 53,98 5,97 138,00 TP-1 SERIES DLC Coated Pin Chamfered H9902750220C 25,15 69,85 5,59 186,00 H SERIES - Chamfered
CA9292425195 23,60 61,60 4,95 138,50 TP-1 SERIES - - H9902750220CD 25,15 69,85 5,59 186,00 H SERIES DLC Coated Pin Chamfered
CA9292425195C 23,60 61,60 4,95 138,50 TP-1 SERIES - Chamfered CA9902750250 25,15 69,85 6,35 203,00 TP-1 SERIES - -
CA9312250215CD 23,65 57,15 5,46 137,80 TP-1 SERIES DLC Coated Pin Chamfered CA9902750250D 25,15 69,85 6,35 203,00 TP-1 SERIES DLC Coated Pin -
CA9312950165 23,65 74,93 4,19 149,00 TP-1 SERIES - - H9902765160 25,15 70,23 4,06 148,00 H SERIES - -
G9402750155 23,88 69,85 3,94 134,00 G SERIES - - H9902765160C 25,15 70,23 4,06 148,00 H SERIES - Chamfered
H9402750155 23,88 69,85 3,94 135,00 H SERIES - - H9902765160D 25,15 70,23 4,06 148,00 H SERIES DLC Coated Pin -
H9402750155D 23,88 69,85 3,94 135,00 H SERIES DLC Coated Pin - H9902930125 25,15 74,42 3,18 126,00 H SERIES - -
G9452500155 24,00 63,50 3,94 122,00 G SERIES - - H9902930135 25,15 74,42 3,43 136,00 H SERIES - -
G9452750155 24,00 69,85 3,94 135,00 G SERIES - - H9902930145 25,15 74,42 3,68 144,00 H SERIES - -
G9452750155C 24,00 69,85 3,94 114,00 G SERIES - Chamfered H9902930145C 25,15 74,42 3,68 143,00 H SERIES - Chamfered
G9752930155 24,77 74,42 3,94 155,00 G SERIES - - H9902930145D 25,15 74,42 3,68 143,00 H SERIES DLC Coated Pin -
G9802750155 24,89 69,85 3,94 142,00 G SERIES - - G9902930155 25,15 74,42 3,94 176,00 G SERIES - -
G9842750155 24,99 69,85 3,94 140,00 G SERIES - - G9902930155C 25,15 74,42 3,94 176,00 G SERIES - Chamfered
H9842750155 24,99 69,85 3,94 143,00 H SERIES - - H9902930155 25,15 74,42 3,94 152,00 H SERIES - -
H9842750155C 24,99 69,85 3,94 143,00 H SERIES - Chamfered H9902930155C 25,15 74,42 3,94 152,00 H SERIES - Chamfered
CA9902500125CD 25,15 63,50 3,18 108,10 TP-1 SERIES DLC Coated Pin Chamfered H9902930155CD 25,15 74,42 3,94 152,00 H SERIES DLC Coated Pin Chamfered
CA9902500140CD 25,15 63,50 3,56 118,10 TP-1 SERIES DLC Coated Pin Chamfered H9902930155D 25,15 74,42 3,94 152,00 H SERIES DLC Coated Pin -
H9902500165 25,15 63,50 4,19 135,00 H SERIES - - H9902930165 25,15 74,42 4,19 160,00 H SERIES - -
H9902500165C 25,15 63,50 4,19 135,00 H SERIES - Chamfered H9902930165C 25,15 74,42 4,19 160,00 H SERIES - Chamfered
H9902500165CD 25,15 63,50 4,19 135,00 H SERIES DLC Coated Pin Chamfered H9902930165CD 25,15 74,42 4,19 160,00 H SERIES DLC Coated Pin Chamfered
H9902500165D 25,15 63,50 4,19 135,00 H SERIES DLC Coated Pin - H9902930165D 25,15 74,42 4,19 160,00 H SERIES DLC Coated Pin -
H9902500175 25,15 63,50 4,45 142,00 H SERIES - - H9902930175 25,15 74,42 4,45 168,00 H SERIES - -
H9902500175C 25,15 63,50 4,45 142,00 H SERIES - Chamfered H9902930175C 25,15 74,42 4,45 168,00 H SERIES - Chamfered
CA9902500185CD 25,15 63,50 4,70 148,20 TP-1 SERIES DLC Coated Pin Chamfered H9902930175CD 25,15 74,42 4,45 168,00 H SERIES DLC Coated Pin Chamfered
H9902500185 25,15 63,50 4,70 148,00 H SERIES - - H9902930175D 25,15 74,42 4,45 168,00 H SERIES DLC Coated Pin -
H9902500185C 25,15 63,50 4,70 148,00 H SERIES - Chamfered CA9902930185 25,15 74,42 4,70 175,20 TP-1 SERIES - -
H9902500185CD 25,15 63,50 4,70 148,00 H SERIES DLC Coated Pin Chamfered CA9902930185CD 25,15 74,42 4,70 175,20 TP-1 SERIES DLC Coated Pin Chamfered
H9902500185D 25,15 63,50 4,70 148,00 H SERIES DLC Coated Pin - CA9902930185D 25,15 74,42 4,70 175,20 TP-1 SERIES DLC Coated Pin -
H9902500195 25,15 63,50 4,95 154,00 H SERIES - - G9902930185 25,15 74,42 4,70 175,00 G SERIES - -
H9902500195C 25,15 63,50 4,95 154,00 H SERIES - Chamfered G9902930185C 25,15 74,42 4,70 175,00 G SERIES - Chamfered
H9902500205 25,15 63,50 5,21 160,00 H SERIES - - H9902930185 25,15 74,42 4,70 176,00 H SERIES - -
H9902500205C 25,15 63,50 5,21 160,00 H SERIES - Chamfered H9902930185C 25,15 74,42 4,70 176,00 H SERIES - Chamfered
H9902500205CD 25,15 63,50 5,21 160,00 H SERIES DLC Coated Pin Chamfered H9902930185CD 25,15 74,42 4,70 176,00 H SERIES DLC Coated Pin Chamfered
H9902500205D 25,15 63,50 5,21 160,00 H SERIES DLC Coated Pin - H9902930185D 25,15 74,42 4,70 176,00 H SERIES DLC Coated Pin -
H9902750135 25,15 69,85 3,43 128,00 H SERIES - - H9902930195 25,15 74,42 4,95 183,00 H SERIES - -
