P. 1150
51-58
Heater and AC-AC compressor
(e). Disassemble clamp by clamp pliers and
take off electromagnet.
4. Assemble electromagnetic clutch of
compressor
(a). Assemble electromagnet.
Hint:
Align with the installation mark.
(b). Use a new clamp.
51
(c). Assemble belt pulley and use a new
clamp.
Notes:
Do not change the combination state before
disassembly of the electromagnetic
clutch.
(d). Install compressor onto bench vice.
(e). Fix the electromagnetic clutch by bench
vice and fasten the bolt.
