Circuit- Guide to the circuit

Rated Rated
S/N Name S/N Name
current current
F21 5A Fuse, ABS control unit F24 15A Fuse, front fog lamp
F22 10A Fuse, AC F25 15A Fuse, ignition switch

F23 15A Fuse, Power of ABS control unit

24V relay

S/N Name S/N Name
R10 Relay, light R13 Relay, blower
R11 Relay, light changing R14 Relay, IG power
R12 Relay, power window R15 Relay, electromagnetic crutch

24V small relay

S/N Name S/N Name
R30 Relay, left highbeam R34 Relay, horn
R31 Relay, right highbeam R35 Relay, AC switching off
R32 Relay, small lamp R36 Main relay, AC

R33 Relay, front fog lamp
