P. 1395
61-123
Circuit- Layout of wire and parts
Layout of wire and parts
ABS wire
61
A002 Right front wheel speed sensor A007 Left rear wheel solenoid valve
A003 Right front wheel solenoid valve A008 Right rear wheel speed sensor
A004 Left front wheel solenoid valve A009 Right rear wheel solenoid valve
A005 Left front wheel speed sensor A101 Wire insert parts (connect to chassis wire)
A006 Left rear wheel speed sensor Grounding, ABS frame left front side
A201
member
