72-6
Windscreen/Window glass/Rearview mirror-Front Windscreen
17. Clean the vehicle body
(a). Clean and refit the contact face of the
body.
· Take off coarse glass sealant from the
contact surface of body by knife.
· Clean the contact face of body by a piece
of cloth soaked by detergent.
Notes:
· Be careful and do not damage the
body.
· Clean the body even if all glass sealant
are removed.
18. Clean inside trimming strip of the windscreen
Hint:
72 Replace the inside trimming strip of the windscreen if it is damaged or deformed.
(a). Take off the adhesive tape and binder from inside trimming strip of the windscreen by scraper.
Notes:
It is strictly not allowed to clean the outside around of the inside trimming strip of the
windscreen by dissoluble detergent.
19. Assemble the glass positioning clips
(a). Assemble 2 glass positioning clips as shown in the figure.
Hint:
Replace the glass positioning clip if it is not tight any more.
