P. 1441
72-29
Windscreen/Window glass/Rearview mirror- Door glass
Door glass
Replacement
Hint:
The replacement steps are same for left and right side glass because they are symmetrical.
1. Disassemble left door glass (refer to “Chapter 72 Windscreen/Window glass/Rearview
mirror-Door glass regulator, Replacement”)
2. Disassemble the glass clip of left door
glass
Hint:
The flat face of door glass clip should face to
outside direction of the vehicle body during
assembly. 72
out
3. ssemble glass clip of left door
Note:
The glass clip of left door should be fixed firmly.
