11-12
Fuel-Fuel filter

8. Installing fuel filter element
(a) Coat fuel filter seal ring with a little
lubricant.
(b) Tighten fuel filter element clockwise
using fuel filter wrench.
Notice:
Overtightening a fuel filter will cause thread
deformation and damage to filter element
gasket or filter tank.

9. Connecting fuel filter harness
11 (a) As shown in the figure, connect the 2
connectors of the fuel filter harness.

10. Connecting battery negative cable
11. Bleeding fuel system
(a) Bleed the fuel system by pressing the
manual pump handle on the fuel filter
several times.

12. Inspection
After making sure all connectors have been connected properly, turn on ignition switch to check
fuel gauge on the meter for normal display and start the engine and check fuel pipe joints of the fuel
system for oil ooze and leak.
