21-10
Front Suspension-Front Suspension Assembly

(f) Jack up front axle slowly, and slip head
of leaf spring center bolt into front axle
locating hole.

(g) Install stopper, front leaf spring cover,
and U-bolts, and tighten nuts of the bolts.

Torques:

Vehicle model Torque
1051 series 199~243 N•m
1061 series 199~243 N•m
1089 series 287~366 N•m

21

9. Installing left front shock absorber (refer to “Chapter 21 Front Suspension-Front
Shock Absorber, Overhaul”)

10. Retighten nuts of U-bolts after a 3~5km travel.

Torques:
Vehicle model Torque
1051 series 199~243 N•m
1061 series 199~243 N•m
1089 series 287~366 N•m

11. Removing right front leaf spring assembly
Tip:

Follow the same removal steps for left front leaf spring assembly to remove right front leaf spring
assembly.
