EXAFIT HP RANGE – WHY HIGH PERFORMANCE?
HIGH PERFORMANCE FOAM
 Faster dynamic response whatever the hardness;
 Better resilience characteristic for improved absorption of mechanical vibration and variability of substrate;
 Consistency of performance whatever the machine setting conditions;
 Wider range of hardness and more reactive foam performance for a better solution to the most demanding
printing jobs.

HIGH PERFORMANCE LINER
 Flexible and smooth liner for easy removability and improved handling performance and accurate positioning;
 Embossed which allows air bubbles to be removed easily;
 Transparent liner for a clear and quick identification.

EXAFIT SCAPA HP RANGE – ADHESIVE TECHNOLOGY
HIGH PERFORMANCE ACRYLIC ADHESIVE ON CYLINDER SIDE WITH DIFFERENT ADHESIVE LEVELS ON PLATE SIDE
Standard adhesive, range – 0:
 Product Reference: all products references ending with 0 HP, as example 43220 HP:
o Where standard adhesion to plate is required;
o Good compromise between tack and adhesion levels;
o Easy repositioning and demounting properties;
o Dedicated for thin and large plates;
o Good demounting through minimal increase of adhesion.

Higher adhesive, range – 1:
 Product Reference: all products references ending with a 1 HP, as example 43221 HP:
o Specifically used on small cylinders;
o Specifically used on rigid & thicker plates;
o Specifically used on high speed machines;
o Adhesive properties prevent plate lifting;
o Removable without leaving adhesive residues behind on plate surface.
