MOBILE FLOOR CRANE

 A must for the removal and installation of engines.

 Heavy duty steel frame construction and caster wheels.

 5 Boom extensions.

 Designed and fabricated in Australia to comply with AS/NZS 1418-1996. FLOOR CRANE

Part Working Load Base Size Overall Max. Boom Max Boom Net
Number Limit L x W Height Height Length Weight
RKFC1500B 1,500kg 1,800mm x 1,560mm 2,500mm 1,700mm 150kg
1,100mm

FOLDING TRUCK MOUNTED CRANE

TM
RITCH REN5A manual operated hydraulic crane with extendable boom supplied with a high quality
alloy hook, is of a high quality with fully-welded construction.
Is compact in design which means it occupies minimum load space, has a manual push slew with a full
360° rotation on taper roller and ball bearings with a locking collar.

Fabricated in Australia
Complies with Australian Standards AS/NZS 1418-1996.

IMPORTANT! TRUCK MOUNTED CRANE
These cranes must be installed and tested in accordance with section 11 of the
Australian Standard.
The manufacturer or reseller accepts no liability for a product not installed in
accordance with this section of the Australian Standard.

Part Number Working Load Limit Overall Height Closed Maximum Lift Height Base Size Net Weight

REN5A 500kg 1330mm 1,710mm 250mm x 250mm 68kg
