RAMS AND ACCESSORIES

FEATURES:

 All models are made of Medium Carbon Steel one solid piece of steel bar is machined
and heat treated to meet the demands of the various environment

 Internal heavy duty return spring provides consistent performance .

 Chrom-plated piston inhibits rusting, scoring and corrosion

 Quick connecting coupler available to all models for fast set up

See Also: Liftech Rams and Accessories on Page 10

RAMS AND ACCESSORIES
RR1
RRS1

RR22
RR10
RRS10

RC26 RF16

Part Working Closed Extended Coupling
Description Stoke
Number Load Limit Height Height Size

RR1 Ram (Threaded) with High flow coupling 11,000kg 369mm 152mm 522mm 3/8” NPT

RRS1 Ram (Slip on) with High flow coupling 11,000kg 369mm 152mm 522mm 3/8” NPT

RR22 Ram (Threaded) with High flow coupling 20,000kg 285mm 127mm 412mm 3/8” NPT

RC26 Spreader Ram with High flow coupling N/A N/A N/A N/A N/A

RF16 Rubber Angle Head (both threaded or Slip-on) N/A N/A N/A N/A N/A

RR10 Ram (Threaded) with High flow coupling 11,000 kg 453mm 254mm 707mm 3/8” NPT

RRS10 Ram (Slip on) with High flow coupling 11,000 kg 463mm 254mm 717mm 3/8” NPT
