Measuring aids
Feeler gauges

Feeler gauges

Application: Execution:
Suitable for inspecting gap dimensions and setting ƒ Gauge blades made from hardened spring steel
clearances. ƒ Conical
ƒ Can be fixed in sheath

Min./max. length of Number of sheets
application area Nominal dimension in assortment (PCS) Length (mm) Width (mm)
010
Ident. No.
36180... 0.04-0.15 mm 0.04-0.10 mm, increasing by 8 100 13 Set price, € O. R.
0.01 mm, 0.15 mm
010
Ident. No.
36181... 0.05-0.5 mm 0.05-0.3 mm, increasing by 8 100 13 Set price, € O. R.
0.05 mm, 0.4 mm, 0.5 mm
0.05-0.3 mm, increasing by 010
Ident. No.
36182... 0.05-1 mm 0.05 mm, 0.4-1.0 mm, increasing 13 100 13 Set price, € O. R.
by 0.1 mm
010
Ident. No.
36183... 0.05-1 mm 0.05-1.0 mm, increasing by 20 100 13 Set price, € O. R.
0.05 mm
010
Ident. No.
36184... 0.1-2 mm 0.1-2.0 mm, increasing by 0.1 mm 20 100 13 Set price, € O. R.
Prod. group 3BF
Measuring equipment
Feeler gauges
Precision design DIN 2275
?
Application: Execution:
Suitable for inspecting gap dimensions and setting ƒ Gauge blades made from hardened spring steel
clearances. ƒ Conical
ƒ Can be fixed in nickel-plated sheath
Min./max. length of Nominal dimension in assortment Number of sheets Length (mm) Width (mm)
application area (PCS)
Ident. No.
008
36189... 0.05-0.5 mm 0.05-0.3 mm, increasing by 0.05 8 100 13 Set price, € O. R.
mm, 0.4 mm, 0.5 mm
0.05-0.3 mm, increasing by 0.05
Ident. No.
013
36189... 0.05-1 mm mm, 0.4-1.0 mm, increasing by 13 100 13 Set price, € O. R.
0.1 mm
020
Ident. No.
36189... 0.05-1 mm 0.05-1.0 mm, increasing by 0.05 20 100 13 Set price, € O. R.
mm
Prod. group 3BF
Feeler gauge strips, dimensions 13 mm x 5 m
Application: ƒ Ident. No. 008–100: Gauge strip marked with
For use in various areas of mechanical engineering, dimensions
e.g. measuring dimensional tolerance between 2
components, as alignment references etc. scope of supply and services:
In can
Execution:
ƒ Made from high carbon steel, hardened Technical Data:
ƒ Suitable for feeler gauge assortment in wall- ƒ Length: 5 m
ƒ Width: 13 mm
mounted holder
Nominal thickness (mm) 0.01 0.02 0.03 0.04 0.05 0.06 0.07 0.08
008
004
003
002
007
Ident. No.
005
006
36225... Unit price, € 001 O. R. O. R. O. R. O. R. O. R. O. R. O. R.
O. R.
Nominal thickness (mm) 0.09 0.1 0.12 0.15 0.18 0.2 0.25 0.3
025
010
Ident. No.
020
018
015
012
030
36225... Unit price, € 009 O. R. O. R. O. R. O. R. O. R. O. R. O. R.
O. R.
Nominal thickness (mm) 0.35 0.4 0.45 0.5 0.55 0.6 0.65 0.7
070
065
045
050
Ident. No.
040
055
060
36225... Unit price, € 035 O. R. O. R. O. R. O. R. O. R. O. R. O. R.
O. R.
Nominal thickness (mm) 0.75 0.8 0.85 0.9 0.95 1
Ident. No.
100
080
090
085
095
36225... Unit price, € 075 O. R. O. R. O. R. O. R. O. R.
O. R.
Prod. group 3BF
