Measuring aids
Vee blocks/Concentricity test devices

Parallels with v-shaped recesses
Special cast iron
?

Application: ƒ Finely ground
For checking, marking off and aligning cylindrical
parts. Technical Data:
ƒ Flatness tolerance: 0.016 mm
Execution: ƒ Angle: 90 Degree
ƒ Machined in pairs
Length x width x height 75 x 150 x 130 mm 90 x 200 x 170 mm
Min./max. workpiece Ø 8-120 mm 10-180 mm
011
021
Ident. No.
35213... Price/pair, € O. R. O. R.
Prod. group 3BE
Concentricity gauge
Lightweight design

Application: ƒ The measuring stand can be moved and locked on
For measuring the axial and radial run-out precision the rear slotted beam
Measuring equipment
of shafts.
Technical Data:
Execution: ƒ Point height: 75 mm
ƒ Clamping table made of hard anodised aluminium ƒ Max. point width: 340 mm
profile with guide groove ƒ Base plate length: 500 mm
ƒ 2 movable tailstocks with hardened, ground 60° ƒ Base plate width: 60 mm
ƒ Groove width: 10 mm
tip/diameter 16 mm, 1 tailstock with movable ƒ Weight: 6.4 kg
clamping tip (hub approx. 10 mm)
010
Ident. No.
35471... Unit price, € O. R.
Prod. group 3BE
Twist drill grinding gauges
Application: ƒ Grinding gauge angle 121° (produces tip angle
For inspecting the tip angle (118°) of twist drills 118°)
Execution:
ƒ Suitable for drills up to 50 mm
Ident. No.
010
36001... Unit price, € O. R.
Prod. group 3BF
Chamfer vernier callipers

Application: scope of supply and services:
For inspecting chamfer angles and dimensional In a case
accuracy
Technical Data:
Execution: ƒ Min./max. length measuring range: 0-10 mm
ƒ With interchangeable inspection straight edges for ƒ Vernier scale: 0.1 mm
30°, 45° and 60° chamfers
010
Ident. No.
36030... Unit price, € O. R.
Prod. group 3BF
