Marking and height measuring devices
Marking devices

Dividers

Application: ƒ Three-part milled joint
For marking dimension lines, e.g. for hole circles. ƒ Finely ground, hardened tips
Execution: ƒ With wing
ƒ Rivet hinge, forged
Length (mm) 150 200 250 300 500
015
050
020
025
030
Ident. No.
35003... Unit price, € O. R. O. R. O. R. O. R. O. R.
Prod. group 3BG
Spring dividers
Application: ƒ Strong annular spring and hardened pivot pins for
For marking dimension lines, e.g. for hole circles. firm control of legs
ƒ Hardened tips
Execution:
ƒ Quick-action clamping nut and particularly strong Measuring equipment
legs
Length (mm) 125 175 225 300
Ident. No.
300
175
125
225
35010... Unit price, € O. R. O. R. O. R. O. R.
Prod. group 3BG
Compass caliper
for marking off
?
Application: ƒ No. 35026: Carbide-tipped marking-off arms
For marking off on workpieces by directly setting
the required dimensions. Technical Data:
ƒ Vernier scale: 0.1 mm
Execution: ƒ Limb length: 40 mm
ƒ No. 35025: Hardened steel marking-off arms
Max. length of application area (mm) 150 200 300
Max. Ø (mm) 300 400 600
Ident. No.
200
150
35025... Unit price, € O. R. O. R. 300
O. R.
200
Ident. No.
150
35026... Unit price, € (O. R.) O. R. 300
O. R.
Prod. group 3BG
Marking gauge
With fine adjustment
?
Application: ƒ Exchangeable, hardened scribing tip
For precise marking off parallel to the workpiece ƒ Cast iron slide with rectangular stop plate
edge. ƒ With fine adjustment
Execution: Technical Data:
ƒ INOX steel round beam with guide groove ƒ Scale value: 0.1 mm
ƒ Graduation with 1 mm scale interval
Max. working length (mm) 200 300
020
030
Ident. No.
35051... Unit price, € O. R. O. R.
Prod. group 3BG
Marking gauge
With runner
?
Application: ƒ Exchangeable cemented carbide marking-off
For precise marking off parallel to the workpiece needle
edge. ƒ Locking screw
Execution: Technical Data:
ƒ INOX steel beam ƒ Max. working length: 200 mm
ƒ Scale value: 0.1 mm
Ident. No.
011
35052... Unit price, € O. R.
Prod. group 3BG
Accessories for 35052 011
35052... Spare scribing tips For Ident. No. 501
marking gauges with runners Set price, € O. R.
