Measuring aids
Concentricity test devices/Small gauges
Radius gauges
concave and convex
Application: Execution:
For testing inner and outer radii Blades fixed with clamping screws
No. 36130
Material Steel Stainless steel
Number of sheets Cutting edge length
(PCS) Radius sizes in assortment (mm)
010
020
Ident. No.
36130... 17 1-3 mm, increasing by 0.25 mm, 3.5-7 70 Set price, € O. R. O. R.
mm, increasing by 0.5 mm
020
010
Ident. No.
36131... 16 7.5-15 mm, increasing by 0.5 mm 85 Set price, € O. R. O. R.
020
010
Ident. No.
36132... 15 15.5-20 mm, increasing by 0.5 mm, 85 Set price, € O. R. O. R.
21-25 mm, increasing by 1 mm
Prod. group 3BF
Screw pitch gauges
milled
Measuring equipment
Application: No. 36054: For metric threads, Whitworth threads
For testing thread pitch using the light gap method and Whitworth pipe threads
Execution:
No. 36053: For metric threads, Whitworth threads
Number of sheets (PCS) 36053... 36054...
ID no. ID no.
52 010 O. R. - -
58 - - 010 O. R.
Set price, €
Prod. group 3BF
Thread lathe tool gauges
Application: Execution:
For testing flank angles of thread cutting tools. No. 36060: For 55° Whitworth threads
No. 36061: For 60° metric threads
Ident. No.
010
36060... Unit price, € O. R.
010
Ident. No.
36061... Unit price, € O. R. No. 36060
Prod. group 3BF
Thread cutting gauge
Application: Trapezoidal thread in line with DIN 103, pitch
For inspecting thread cutting tools 2–12 mm
Flank angle 30°
Execution: Sharp V thread 55° and 60°
With recesses for square threads, 2–8 starts per
1”
010
Ident. No.
36075... Unit price, € O. R.
Prod. group 3BF
