Tools for threads
Metal cutting tools
Machine tap

Cutting material HSSE HSSE
Surface Uncoated Uncoated
Tolerance of screw taps ISO 2 (6H) ISO 2 (6H)
Lead angle shape C C
CNC,
Application type/machine type Conventional Conventional
Twist angle 40° (right) 40° (right)
Coolant supply External External
DIN 13267... 13268...
Ident. No. Ident. No.
mm mm mm mm mm
M10 1.5 8.5 100 10 8 371 100 O. R. 100 O. R.
M12 1.75 10.2 110 9 7 376 120 O. R. 120 O. R.
M14 2 12 110 11 9 376 140 O. R. - -
M16 2 14 110 12 9 376 160 O. R. - -
M18 2.5 15.5 125 14 11 376 180 O. R. - -
M20 2.5 17.5 140 16 12 376 200 O. R. - -
M24 3 21 160 18 14.5 376 240 O. R. - -
M30 3.5 26.5 180 22 18 376 300 O. R. - -
M36 4 32 180 28 22 376 360 O. R. - -
Unit price, €
ORION = Prod. Gr. 1DB
a = Prod. Gr. 131
Machine tap HSSE
for universal conventional use up to 1000 N/mm 2 DIN 376

conv.
M HSSE
2,5xd C (2-3)
Application: Advantage:
For manufacturing metric threads in blind holes ƒ Long service life and high process reliability thanks
on conventional machines in the steel, (stainless to innovative cutting geometry, and universal use
steel), NF metals and (cast) material groups up to a for maximum flexibility in use.
strength of 1000 N/mm . 2
Execution:
ƒ With transition-fit shank
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
13326020-100 16 11 9 18 18 15 18 15 15 13 16
13326120-200 16 11 9 18 18 15 18 15 15 13 16
Cutting material HSSE
Surface Uncoated
Tolerance of screw taps ISO 2 (6H)
Lead angle shape C
Application type/machine type Conventional
Twist angle 40° (right)
Coolant supply External
DIN 13326...
Ident. No.
mm mm mm mm mm
M2 0.4 1.6 45 1.6 - 376 020 O. R.
M2.5 0.45 2.05 50 1.8 - 376 025 O. R.
M3 0.5 2.5 56 2.2 - 376 030 O. R.
M3.5 0.6 2.9 56 2.5 2.1 376 035 O. R.
M4 0.7 3.3 63 2.8 2.1 376 040 O. R.
M5 0.8 4.2 70 3.5 2.7 376 050 O. R.
M6 1 5 80 4.5 3.4 376 060 O. R.
M8 1.25 6.8 90 6 4.9 376 080 O. R.
M10 1.5 8.5 100 7 5.5 376 100 O. R.
M12 1.75 10.2 110 9 7 376 120 O. R.
M14 2 12 110 11 9 376 140 O. R.
M16 2 14 110 12 9 376 160 O. R.
M18 2.5 15.5 125 14 11 376 180 O. R.
M20 2.5 17.5 140 16 12 376 200 O. R.
Unit price, €
Prod. Gr. 131
