Tools for threads
Machine tap
Machine tap HSSE DIN 371
for universal use up to 1000 N/mm2
Metal cutting tools
Metal cutting tools
CNC/conv.
M HSSE
2,5xd E (1,5-2)
Application: Advantage:
For creating metric threads in the blind hole nearly good service life and process reliability thanks to
to the base on CNC or conventional machines for innovative cutting geometry and universal use for
the material groups of steel, (stainless steel), non- the greatest flexibility in applications
ferrous metals and (cast iron) up to a strength of thread cutting nearly to the thread base
1000 N/mm . 2
Execution:
with reinforced shank
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
13311 17 12 10 19 19 17 19 17 17 15 18
Cutting material HSSE
Surface Vaporised
Tolerance of screw taps ISO 2 (6H)
Lead angle shape E
Application type/machine type CNC,
Conventional
Twist angle 40° (right)
Coolant supply External
DIN 13311...
Ident. No.
mm mm mm mm mm
M3 0.5 2.5 56 3.5 2.7 371 030 O. R.
M4 0.7 3.3 63 4.5 3.4 371 040 O. R.
M5 0.8 4.2 70 6 4.9 371 050 O. R.
M6 1 5 80 6 4.9 371 060 O. R.
M8 1.25 6.8 90 8 6.2 371 080 O. R.
M10 1.5 8.5 100 10 8 371 100 O. R.
Unit price, €
Prod. Gr. 131
Oversize machine tap, HSSE DIN 371
for universal use up to 1000 N/mm2
CNC/conv.
M HSSE
3xd B (3,5-5)
Application: Execution:
For creating metric threads with ISO 3 oversize (for with reinforced shank
subsequent surface treatment or shrinking of the
thread in the course of hardening) in the through Advantage:
hole on CNC or conventional machines for the mate- good service life and process reliability thanks to
rial groups of steel, (stainless steel), non-ferrous innovative cutting geometry and universal use for
metals and (cast iron) up to a strength of 1000 N/ the greatest flexibility in applications
mm . 2
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
13116 17 12 10 19 19 17 19 17 17 15 18
Cutting material HSSE
Surface Vaporised
Tolerance of screw taps ISO 3 (6G)
Lead angle shape B
Application type/machine type CNC,
Conventional
Twist angle 0°
Coolant supply External
DIN 13116...
Ident. No.
mm mm mm mm mm
M3 0.5 2.5 56 3.5 2.7 371 030 O. R.
M4 0.7 3.3 63 4.5 3.4 371 040 O. R.
M5 0.8 4.2 70 6 4.9 371 050 O. R.
M6 1 5 80 6 4.9 371 060 O. R.
M8 1.25 6.8 90 8 6.2 371 080 O. R.
M10 1.5 8.5 100 10 8 371 100 O. R.
Unit price, €
Prod. Gr. 131
