Tools for threads
Machine tap

Cutting material HSSE-PM Metal cutting tools
Surface TiCN
Tolerance of screw taps ISO 2 (6H)
Lead angle shape C
Application type/machine type CNC,
Conventional
Twist angle 40° (right)
Coolant supply Internal
DIN 13312...
Ident. No.
mm mm mm mm mm
M16 2 14 110 12 9 376 160 O. R.
M20 2.5 17.5 140 16 12 376 200 O. R.
M24 3 21 160 18 14.5 376 240 O. R.
Unit price, €
Prod. Gr. 131
Machine tap, oversized, HSSE DIN 371
For use in high-strength steel up to 1300 N/mm2

CNC/conv.
M HSSE
3xd B (3,5-5)
Application: Execution:
For manufacturing oversized metric threads to ƒ With reinforced shank
ISO 3 (for subsequent surface treatment or thread
shrinking as part of a hardening process) in through Advantage:
holes on CNC and conventional machines in the steel ƒ Long service life and high level of process reli-
material group up to a strength of 1300 N/mm . 2 ability thanks to innovative cutting geometry and
coating for use in high-strength steel
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
13077030-100 16 12 9
Cutting material HSSE
Surface Vaporised
Tolerance of screw taps ISO 3 (6G)
Lead angle shape B
Application type/machine type CNC,
Conventional
Twist angle 0°
Coolant supply External
DIN 13077...
Ident. No.
mm mm mm mm mm
M3 0.5 2.5 56 3.5 2.7 371 030 O. R.
M4 0.7 3.3 63 4.5 3.4 371 040 O. R.
M5 0.8 4.2 70 6 4.9 371 050 O. R.
M6 1 5 80 6 4.9 371 060 O. R.
M8 1.25 6.8 90 8 6.2 371 080 O. R.
M10 1.5 8.5 100 10 8 371 100 O. R.
Unit price, €
Prod. Gr. 131
Oversize machine tap, HSSE DIN 371
for use in high-strength steel up to 1300 N/mm2

CNC/conv.
M HSSE
2,5xd C (2-3)
Application: Execution:
For creating metric threads with ISO 3 oversize (for ƒ with reinforced shank
subsequent surface treatment or shrinking of the
thread in the course of hardening) in the blind hole Advantage:
on CNC or conventional machines for the material ƒ good service life and process reliability thanks
group of steel up to a strength of 1300 N/mm . 2 to innovative cutting geometry for use in high-
strength steel
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
13309 16 12 9
