Tools for threads
Machine tap
Machine tap HSSE DIN 371 Metal cutting tools
For use in stainless steels
CNC/conv.
M HSSE
3xd B (3,5-5)
Application: Advantage:
For machining metric threads in through holes on Innovative cutting geometry with exposed teeth
CNC and conventional machines in the stainless reduces the torque, improves lubricant distribution
steel material group. and ensures very high process reliability and chip
removal
Execution: Specialised insert with optimised chipping geom-
With exposed teeth and reinforced shank etry for use in stainless steels with adhesive or
lubricating properties
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
13088 16 11 9 10
Cutting material HSSE
Surface Uncoated
Tolerance of screw taps ISO 2 (6H)
Lead angle shape B
Application type/machine type CNC,
Conventional
Twist angle 0°
Coolant supply External
DIN 13088...
Ident. No.
mm mm mm mm mm
M3 0.5 2.5 56 3.5 2.7 371 030 O. R.
M4 0.7 3.3 63 4.5 3.4 371 040 O. R.
M5 0.8 4.2 70 6 4.9 371 050 O. R.
M6 1 5 80 6 4.9 371 060 O. R.
M8 1.25 6.8 90 8 6.2 371 080 O. R.
M10 1.5 8.5 100 10 8 371 100 O. R.
Unit price, €
Prod. Gr. 131
Machine tap HSSE DIN 376
For use in stainless steels
CNC/conv.
M HSSE
3xd B (3,5-5)
Application: Advantage:
For manufacturing metric threads in through holes in Long service life and high process reliability
the stainless steel material group on CNC or conven- through innovative cutting geometry when
tional machines. machining stainless steel
Execution:
With transition-fit shank
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
13215030-300 16 12 9 10
Cutting material HSSE
Surface Vaporised
Tolerance of screw taps ISO 2 (6H)
Lead angle shape B
Application type/machine type CNC,
Conventional
Twist angle 0°
Coolant supply External
DIN 13215...
Ident. No.
mm mm mm mm mm
M3 0.5 2.5 56 2.2 - 376 030 O. R.
M4 0.7 3.3 63 2.8 2.1 376 040 O. R.
M5 0.8 4.2 70 3.5 2.7 376 050 O. R.
M6 1 5 80 4.5 3.4 376 060 O. R.
M8 1.25 6.8 90 6 4.9 376 080 O. R.
M10 1.5 8.5 100 7 5.5 376 100 O. R.
M12 1.75 10.2 110 9 7 376 120 O. R.
M14 2 12 110 11 9 376 140 O. R.
M16 2 14 110 12 9 376 160 O. R.
M18 2.5 15.5 125 14 11 376 180 O. R.
M20 2.5 17.5 140 16 12 376 200 O. R.
M24 3 21 160 18 14.5 376 240 O. R.
M30 3.5 26.5 180 22 18 376 300 O. R.
Unit price, €
Prod. Gr. 131
