Drilling tools
High-performance drill UNI
High-performance drill, solid carbide TiAlNplus HPC 12xD
for universal use up to 1300 N/mm 2
Metal cutting tools
Metal cutting tools
TiAlN HPC HA HB HE
VHM
plus UNI IK Ident. No. 030–200
12xD 140°
Application: close contour TiAlNplus coating for extra service
Ident. No. 030–400: For HPC drilling in steel (stain- life Ident. No. 230–400
less steel), non-ferrous metal, cast and (special Cutting edge conditioning minimises micro-
alloy) material groups up to a strength of 1300 N/ cracks in the cutting edge
mm . 2 High quality: state-of-the-art grinding technology Ident. No. 430–600
Ident. No. 430–600: For HPC boring for the material guarantees a high concentricity of tools and
groups of steel, (stainless steel), non-ferrous metals, precision of the tool cutters. 4 guiding chamfers
cast iron and (special alloys) up to a strength of 1300 for high drilling accuracy
N/mm . 2 Ident. No. 430–600:
universal HPC cutting edge geometry: excellent
Execution: all-round properties and precise cutting proper-
Ident. No. 030–400: Heavy-duty drill, solid ties with high cutting rates and very long service
carbide TiAlNplus with universal precision grinding life
Ident. No. 430–600: high-performance drill, solid latest coating technology: unique, extremely
carbide TiAlNplus with universal precision grinding hard, low-friction, temperature-resistant and
close-contour TiAlN plus coating provides added
Advantage: service life
Ident. No. 030–400: cutting edge preparation minimises microfrac-
Universal HPC cutting geometry: excellent all- tures in the blade
round properties and precise cutting properties quality standard: state-of-the-art grinding
with high cutting rates and very long service life technology guarantees excellent concentricity
Latest coating technology: unique, extremely of tools and precision in the cutter design of
hard, low-friction, temperature-resistant and tools. Four guide chamfers ensure high degree of
drilling precision
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
11198030-200 130 100 80 30 30 200 250 230 180 160 130 60 100 40 35 30
11198230-400 130 100 80 30 30 200 250 230 180 160 130 60 100 40 35 30
11198430-600 130 100 80 30 30 200 250 230 180 160 130 60 100 40 35 30
Tool holding device HA parallel HB parallel HE parallel
shank shank shank
Surface TiAlN plus TiAlN plus TiAlN plus
Coolant supply Internal Internal Internal
f steel 1000 11198... 11198... 11198...
h6 (mm/U) ID no. ID no. ID no.
mm mm mm mm
3 6 50 90 0.09 030 O. R. 230 (O. R.) 430 (O. R.)
3.1 6 50 90 0.09 031 O. R. 231 (O. R.) 431 (O. R.)
3.2 6 50 90 0.09 032 O. R. 232 (O. R.) 432 (O. R.)
3.3 6 50 90 0.09 033 O. R. 233 (O. R.) 433 (O. R.)
3.4 6 50 90 0.09 034 O. R. 234 (O. R.) 434 (O. R.)
3.5 6 50 90 0.09 035 O. R. 235 (O. R.) 435 (O. R.)
3.6 6 50 90 0.09 036 O. R. 236 (O. R.) 436 (O. R.)
3.7 6 50 90 0.09 037 O. R. 237 (O. R.) 437 (O. R.)
3.8 6 64 102 0.09 038 O. R. 238 (O. R.) 438 (O. R.)
3.9 6 64 102 0.09 039 O. R. 239 (O. R.) 439 (O. R.)
4 6 64 102 0.09 040 O. R. 240 (O. R.) 440 (O. R.)
4.1 6 64 102 0.09 041 O. R. 241 (O. R.) 441 (O. R.)
4.2 6 64 102 0.09 042 O. R. 242 (O. R.) 442 (O. R.)
4.3 6 64 102 0.09 043 O. R. 243 (O. R.) 443 (O. R.)
4.4 6 64 102 0.09 044 O. R. 244 (O. R.) 444 (O. R.)
4.5 6 64 102 0.09 045 O. R. 245 (O. R.) 445 (O. R.)
4.6 6 64 102 0.09 046 O. R. 246 (O. R.) 446 (O. R.)
4.7 6 64 102 0.09 047 O. R. 247 (O. R.) 447 (O. R.)
4.8 6 78 116 0.09 048 O. R. 248 (O. R.) 448 (O. R.)
4.9 6 78 116 0.09 049 O. R. 249 (O. R.) 449 (O. R.)
5 6 78 116 0.09 050 O. R. 250 (O. R.) 450 (O. R.)
5.1 6 78 116 0.09 051 O. R. 251 (O. R.) 451 (O. R.)
5.2 6 78 116 0.09 052 O. R. 252 (O. R.) 452 (O. R.)
5.3 6 78 116 0.09 053 O. R. 253 (O. R.) 453 (O. R.)
5.4 6 78 116 0.09 054 O. R. 254 (O. R.) 454 (O. R.)
5.5 6 78 116 0.1 055 O. R. 255 (O. R.) 455 (O. R.)
5.6 6 78 116 0.1 056 O. R. 256 (O. R.) 456 (O. R.)
5.7 6 78 116 0.1 057 O. R. 257 (O. R.) 457 (O. R.)
5.8 6 78 116 0.1 058 O. R. 258 (O. R.) 458 (O. R.)
5.9 6 78 116 0.1 059 O. R. 259 (O. R.) 459 (O. R.)
6 6 78 116 0.1 060 O. R. 260 O. R. 460 (O. R.)
6.1 8 108 146 0.1 061 O. R. 261 (O. R.) 461 (O. R.)
6.2 8 108 146 0.1 062 O. R. 262 (O. R.) 462 (O. R.)
6.3 8 108 146 0.1 063 O. R. 263 (O. R.) 463 (O. R.)
6.4 8 108 146 0.1 064 O. R. 264 (O. R.) 464 (O. R.)
6.5 8 108 146 0.11 065 O. R. 265 (O. R.) 465 (O. R.)
6.6 8 108 146 0.11 066 O. R. 266 (O. R.) 466 (O. R.)
6.7 8 108 146 0.11 067 O. R. 267 (O. R.) 467 (O. R.)
6.8 8 108 146 0.11 068 O. R. 268 (O. R.) 468 (O. R.)
6.9 8 108 146 0.11 069 O. R. 269 (O. R.) 469 (O. R.)
7 8 108 146 0.11 070 O. R. 270 (O. R.) 470 (O. R.)
7.1 8 108 146 0.11 071 O. R. 271 (O. R.) 471 (O. R.)
7.2 8 108 146 0.11 072 O. R. 272 (O. R.) 472 (O. R.)
