Drilling tools
Countersink drill bit, solid carbide

180° heavy-duty drill, solid carbide TiAlN 5xD Metal cutting tools
For universal use up to 1000 N/mm 2

HA
VHM TiAlN
5xD 180° IK
Application: Advantage:
For machining holes with a 180° hole bottom in a ƒ Drilling and sinking in a single work step at high
single step in steel, cast and stainless steel material cutting speed
groups in single part and series production. ƒ Innovative geometry ensures good chip removal
Execution:
ƒ Heavy-duty solid carbide drill with 180° precision
grinding and drill heels
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
11168280-400 40 20 12 15 12 60 80 60 40 40 30 30 7 7 10
f steel 11168... f steel 11168...
h6 1000 ˜ ID no. h6 1000 ˜ ID no.
(mm/U) (mm/U)
mm mm mm mm mm mm mm mm
8 8 53 91 0.13 280 O. R. 15 16 81 131 0.18 350 O. R.
9 10 61 103 0.14 290 O. R. 18 18 91 141 0.20 380 O. R.
10 10 61 103 0.14 300 O. R. 20 20 99 151 0.23 400 O. R.
11 12 69 116 0.16 310 O. R. Unit price, €
Prod. group 113
Solid carbide countersink drill bit
for universal use up to 1300 N/mm 2

HA Z
VHM TiN 3
5xD 150°
Application: Advantage: No. 11164
Special geometry with 3 edges for use in the material ƒ special geometry with three edges: innovative
groups of steel, stainless steel, non-ferrous metals, cutting geometry for precise position and shape
and cast iron up to a strength of 1300 N/mm . For drilling into the main body without needing to No. 11166
2
precise position and shape drilling into the main centre
body. Centring is not usually required. ƒ cutting edge handling and cutting material
Execution: quality: consistent raw material quality of K40F
cutting material combined with precise grinding
ƒ No. 11164: countersink drill bit, solid carbide, processes and defined cutting edge rounding No. 11167
uncoated with 3-edge special grinding for minimises microfractures in the blade and provides
machining steels up to 1000 N/mm2 consistent cutting material quality in production
ƒ No. 11166: countersink drill bit, solid carbide processes
TiN with 3-edge special grinding for machining ƒ No. 11164: universal use: wide range of cemented
high-strength steels and long-chipping non-ferrous carbide quality and geometry for highly varied
metals applications; thus increasing service life and
ƒ No. 11167: countersink drill bit, solid carbide, providing a high degree of process stability
uncoated with 3-edge special grinding for ƒ No. 11166: latest coating technology: multilayer
machining steel, cast iron and non-ferrous metals TiAlN coating with a TiN surface layer provides
superior service life and user-friendly wear
detection
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
11164 80 70 50 35 30 170 200 120 100 70 60 50 80
11166 85 75 55 35 30 180 210 140 100 70 60 50 80 30 30 20
11167 85 75 55 35 30 180 210 140 100 70 60 50 90 30 30 20
f steel 1000 ˜ 11164... 11166... 11167...
h6 (mm/U) ID no. ID no. ID no.
mm mm mm mm
3 3 22 46 0.09 030 O. R. 030 O. R. 030 O. R.
3.2 3.2 24 49 0.09 032 O. R. 032 O. R. 032 O. R.
3.3 3.3 24 49 0.09 033 O. R. 033 O. R. 033 O. R.
3.5 3.5 27 52 0.09 035 O. R. 035 O. R. 035 O. R.
3.8 3.8 30 55 0.09 038 O. R. 038 O. R. 038 O. R.
4 4 30 55 0.09 040 O. R. 040 O. R. 040 O. R.
4.2 4.2 30 55 0.09 042 O. R. 042 O. R. 042 O. R.
4.5 4.5 32 58 0.09 045 O. R. 045 O. R. 045 O. R.
4.8 4.8 35 62 0.09 048 O. R. 048 O. R. 048 O. R.
5 5 35 62 0.09 050 O. R. 050 O. R. 050 O. R.
5.5 5.5 39 66 0.1 055 O. R. 055 O. R. 055 O. R.
5.8 5.8 39 66 0.1 058 O. R. 058 O. R. 058 O. R.
6 6 39 66 0.11 060 O. R. 060 O. R. 060 O. R.
6.5 6.5 42 70 0.12 065 O. R. 065 O. R. 065 O. R.
6.8 6.8 45 74 0.12 068 O. R. 068 O. R. 068 O. R.
7 7 45 74 0.12 070 O. R. 070 O. R. 070 O. R.
7.5 7.5 45 74 0.13 075 O. R. 075 O. R. 075 O. R.
7.8 7.8 48 79 0.14 078 O. R. 078 O. R. 078 O. R.
8 8 48 79 0.14 080 O. R. 080 O. R. 080 O. R.
8.5 8.5 48 79 0.15 085 O. R. 085 O. R. 085 O. R.
