1.7 BLEEDING

11WARNING 1WARNING A plugged or covered relief port can cause brake drag or lock-up, which could lead to loss of control, resulting in Verify proper operation of the master cylinder relief port. Actuate the brake lever with the cover removed. A slight spurt of fluid will break the surface if all internal compo- Install gasket and cover on master cylinder. cover screws to 6-8 in-lbs (0.7-0.9 Nm). 11WARNING 1WARNING After repairing the brake system, test brakes at low speed. If brakes are not operating properly, testing at high speeds can cause loss of control, which could Turn ignition switch ON. Pump brake hand lever to verify operation of the br
death or serious injury. (00288a) 5. nents are working properly. 6. result in death or serious injury. (00289a) Test brake system. 7. a. b. BRAKES.

Install pad pins. Pad pins will give an audible click when
inserted into inside housing. Tighten both pad pins to

180-200 in-lbs (20.3-22.6 Nm). NOTE If pad pins do not fit, check the following: You are using a set of pads, not two identical pads. Anti-rattle clip orientation matches Figure 2-71. Pads must be pushed tight against the anti-rattle clip before the pad pins can be installed. INSTALLATION See Figure 2-66. Attach caliper to fork leg. Place caliper over brake disc with bleeder valve fac- ing upwards. Loosely install long mounting bolt (4) (12 pt/10 mm) into top hole on fork leg. Install short mounting bolt (5) (12 pt/10 mm) into bottom hole on fork leg. Tighten bottom mounting bolt to 28-38 ft-lbs (38.51.5 Nm). Final tighten the top mounting bo
