Page 212 - 2020 Allstar Performance Parts and Equipment Catalog

SUSPENSION Rod Ends Jam Nuts - Standard Hex

Allstar jam nuts have many uses. Great for
Two-piece spherical rod
locking rod ends tightly on suspension tubes
ends have a pivoting steel
or rack and pinion steering units. Package of 4,
ball and are sold each.
Bore x Thread
Standard Series Steel
Steel
Size
ALL58004
1/4" x 1/4"-28 RH Male LH Male RH Female Strength unless noted. ALL18250 Aluminum
ALL58014
2,835 Lbs
ALL58034
1/4"-28 RH
–
5/16" x 5/16"-24 ALL58005 ALL58015 ALL58035 4,517 Lbs 1/4"-28 LH ALL18251 –
3/8" x 3/8"-24 ALL58006 ALL58016 ALL58036 6,323 Lbs 5/16"-24 RH ALL18252 –
1/2" x 1/2"-20 ALL58008 ALL58018 ALL58038 10,046 Lbs 5/16"-24 LH ALL18253 –
5/8" x 5/8"-18 ALL58010 ALL58020 ALL58040 15,488 Lbs 3/8"-24RH ALL18254 ALL18274
3/4" x 3/4"-16 ALL58012 ALL58022 ALL58042 15,894 Lbs 3/8"-24 LH ALL18255 ALL18275
3/4" x 3/4"-16‡ ALL58013‡ – – 15,894 Lbs 7/16"-20 RH ALL18256 ALL18276
Pro Series Steel (Moly) – Black 7/16"-20 LH ALL18257 ALL18277
1/2" x 1/2"-20 ALL58058 ALL58068 – 17,000 Lbs 1/2"-20 RH ALL18258 ALL18278
1/2" x 5/8"-18 ALL58059 ALL58069 – 19,300 Lbs 1/2"-20 LH ALL18259 ALL18279
5/8" x 5/8"-18 ALL58060 ALL58070 – 18,000 Lbs 5/8"-18 RH ALL18260 ALL18280
3/4" x 3/4"-16 ALL58062 ALL58072 – 25,000 Lbs 5/8"-18 LH ALL18261 ALL18281
Pro Series Steel (Moly) – Black (PTFE Lined) 3/4"-16 RH ALL18262 ALL18282
1/2" x 5/8"-18 ALL58079 ALL58084 17,650 Lbs 3/4"-16 LH ALL18263 ALL18283
5/8" x 5/8"-18 ALL58080 ALL58085 15,200 Lbs 3/4"-10 RH ALL18264 †‡ –
3/4" x 3/4"-16 ALL58082 ALL58086 21,400 Lbs †
Aluminum – Black 7/8"-9 RH ALL18266 (Sway Bar Adj. Nut) – –
ALL56110 (Jack Bolt Nut)
1"-8 RH
†
1/2" x 1/2"-20 ALL58088 ALL58098 – 7,700 Lbs
1/2" x 5/8"-18 ALL58089 ALL58099 – 15,000 Lbs †Sold Each.
‡Commonly used with UBM35-1107, 3/4"-10 jack bolt.
‡ALL58013 has an oversized hole and is for use with steering shaft tubing.
Steel Jam Nut
Assortments
Heavy Duty 3/4"
Assortments contain five
Chrome Moly Rod Ends each of 1/4"-28, 5/16"-24,
Heavy duty or often referred to as 3/8"-24, 7/16"-20, 1/2"-20,
“Aircraft Style”, these 4130 chrome 5/8"-18 and 3/4"-16.
moly rod ends have larger bodies, ALL18290 ..... 35 Asst. RH Jam Nuts
making them 30%t stronger than stan- ALL18291 ..... 35 Asst. LH Jam Nuts
dard 3/4" rod ends. These rod ends are
commonly used on Panhard bars and Jam Nuts - Small Hex
lower strut rods. ALL99314 ALL99315
Specialty jam nuts have smaller outside
ALL99314 ..... RH Male, 3/4" x 3/4"-16 diameters, allowing smaller wrenches to
ALL99315 ..... RH Female, 3/4" x 3/4"-16 be used when changing radius rod lengths. Example: with
1/2" bolts the same 3/4" wrench can be used to adjust
radius rod or mounting hole locations. Package of 4.
3/4" Solid Rod End ALL58112 Thread Wrench Black
Solid rod ends are built using 1045 steel and are Size Size Steel Alum. Alum.
then chrome plated for added wear resistance. 5/8"-18 RH 3/4" ALL18292 ALL18296 ALL18286
End has a body width of 7/8" to match the width 5/8"-18 LH 3/4" ALL18293 ALL18297 ALL18287
of standard rod ends. 3/4"-16 RH 15/16" ALL18294 ALL18298 ALL18288
3/4"-16 LH 15/16" ALL18295 ALL18299 ALL18289

Bolt Center Caps ALL10678
Caps slip over the head of standard
1/2" bolts to accurately measure
the center-to-center length of
installed suspension tube assemblies.
Machined step secures the end of a standard tape mea-
sure for easy reading of the length to the center of the
opposite cap. Caps feature a built-in O-ring that allows
the cap to swivel on the bolt head and keeps it from
falling off. Package of 2. Paulie Colagiovanni
