2-Piece Limit Chain Clamps Coil-Over Load Bolt Assembly
2-Piece clamp bolts around most 3" ALL56074 SUSPENSION
O.D. axle tubes providing a lower Threaded aluminum bolt is 6" long with 1-1/8"-12
mounting point for a suspension fine threads and is commonly used as an adjust-
limit chain. Two piece design able travel limiter. Also used with ALL56098
features a nylon liner allowing threaded sleeve.
clamp to be installed without ALL56075 ..... Replacement Shock End
removing existing brake brackets and hubs.
ALL68336 ..... Steel
ALL68337 ..... Aluminum
Suspension Limiter
1-Piece Single bushing suspension limiter is com-
Limit Chain Clamps monly used on the chassis LR or RR to limit
travel during acceleration “hike up” and
1-Piece bearing style clamp control roll steer. Dual bushing limiter is
slides over the end of most often used on the lift bar to control lift bar
3" O.D. axle tubes providing travel on deceleration. Bushing design reduces
a lower mounting point for a or absorbs shock when suspension is limited and
suspension limit chain.
helps reduce tire unloading. Top plate is drilled
ALL68332 ..... Steel to attach a 1/2" rod end when used in a shock mount or
ALL68333 ..... Aluminum for attaching to a weight jack bolt with 7/16"-20 internal
threads using optional chrome moly stud ALL64304.
Retainer Clamps, 2-Piece Clevis has a 3/8" hole for simple attachment to a chain or
Retainer clamp bolts around most 3" cable.
O.D. axle tubes to keep bird cages, floater ALL64300 ..... Single Bushing Limiter
brackets, limit chain clamps in position. 2-piece design ALL64302 ..... Dual Bushing Limiter
allows clamp to be installed without removing existing ALL64304 ..... Chrome Moly Stud With Jam Nut
brake bracket and hub.
ALL68338 ..... Steel
ALL68339 ..... Aluminum
Limiter Chain Kit
Retainer Clamps, Commonly used to limit rear
1-Piece suspension or lift bar travel. Chain
can be easily cut to required length.
Steel retainer clamp slides Shrink sleeve installs over chain, and
over the end of most 3" O.D. when heated with a heat gun, shrinks to keep chain in
Lightweight Heavy Duty
axle tubes to keep bird cages, position and prevent chain from binding or catching
floater brackets, and limit chain clamps in position. on itself.
Powder coated black finish. ALL64312 ..... 3/16" Diameter Accepts 3/8" Pin or Bolt
ALL64314 ..... 5/16" Diameter Accepts 1/2" Pin or Bolt
Mounting
Part No. Description Width Thickness Hardware
ALL68326 Lightweight 1/2" 1/8" 1/4"
ALL68328 Lightweight 5/8" 1/8" 3/8" QC Axle Tube
ALL68327 Heavy Duty 5/8" 1/4" 3/8"
Support Brackets
Clamp-On Rings Brackets provide mounting
Steel brackets bolt to 3" axle tubes. Choose points for a strut rod
from five widths in 1-, 2- and 4-bolt designs. assembly to help eliminate ALL68320
ALL60143 ..... 1-Bolt, 5/8" Wide flex found in quick change ALL68322
ALL60143
ALL60144 ..... 2-Bolt, 1" Wide rear ends. ALL68320 attaches to
ALL60145 ..... 2-Bolt, 1-3/4" Wide the side bell bolts on most quick Suspension Tubes
See Page 200
ALL60146 ..... 2-Bolt, 2" Wide change rear ends. ALL68322 has
ALL60147 ..... 4-Bolt, 3" Wide ALL60145 tabs with 1/2" holes and mounts
directly onto a 3" axle tube.
Axle Tube Bracket ALL68324 ALL68320 ..... Center Section Mount ALL68320
Bracket clamps around 3" wide axle tubes ALL68322 ..... Axle Tube Mount ALL68322
to provide a mounting point for a suspen-
sion limiter such as a limiting strap or chain.
1" wide bracket has tabs with 1/2" holes.
