TOOLS & PIT EQUIPMENT
Tubing Notchers Smart Tool ALL10113
Notchers render precise joints for Ensure that chassis tubing is level
more consistent welds and and plumb when building roll
stronger cages. Available cages or checking driveshaft angles.
in deluxe aluminum or Powered by a standard 9 volt battery.
economy steel versions,
notchers accept up to 2" Level Base ALL10741
diameter stock and auto-
matically align and center Level base simplifies notching
tubing. Use in drill press or and bending of round tubing
with hand drill. Notchers adjust ALL10411 and helps ensure accuracy. Base fastens
up to 45°. to standard ballast or weight brackets
and clamps to the tube as a reference
ALL10400 ..... Deluxe Aluminum ALL10400 point when creating parallel, perpendic-
ALL10411 ...... Economy Steel ALL10402 ALL10403
ular, any angle of opposing notches or Digital scale and
Replacement Parts bends during fabrication. Base accepts mounting bracket
ALL10402 ..... 5/8"-18 Thread Adapter most digital levels including ALL10113, sold separately.
ALL10403 ..... Arbor Support Bushings (Pair) ALL10742 and ALL10744 or standard bubble levels.
ALL10404 ..... Arbor With 1/2"-20 Thread Individual Mounting Brackets
Optional Parts ALL14192 ... 1" ALL14195 ... 1-1/2"
ALL10405 ..... Arbor With 5/8"-18 Thread ALL10406 ALL10407 ALL14193 ... 1-1/4" ALL14196 ... 1-5/8"
ALL10406 ..... Drill Press Mount (ALL10411 Only) ALL14194 ... 1-3/8" ALL14197 .... 1-3/4"
ALL10407 ..... Arbor Support With Needle Bearings ALL14195
Note: Tubing notchers include 1/2"-20 arbor thread and 5/8"-18 adapter. Hole Smart Tool Tray ALL10740
saws up to 1-1/8" diameter use 1/2"-20, larger hole saws use 5/8"-18 thread.
Aluminum tray is a nice addition when using Smart Tool
on 7/8" and 1" O.D. trailing arms or suspension
tubes. Plastic clips allow tray to snap
Hole Saw Set ALL10412 to tube when in tight areas.
Use with tubing notchers. Does not A bubble level helps provide
include an arbor for a hand drill. Set accurate readings.
includes one of each size: 3/4", 1", 1-1/8",
1-1/4", 1-1/2" 1-5/8" and 1-3/4". Punch And Flare Tools
Individual Hole Saws Add strength and a smooth finish
ALL10413 ...... 3/4" ALL10417 ...... 1-1/2" to hole edges. Unique tools can be
ALL10414...... 1" ALL10418 ...... 1-5/8" used to punch and flare new holes, or
ALL10415 ...... 1-1/8" ALL10419 ...... 1-3/4" to flare existing holes. Starting with a
ALL10416 ..... 1-1/4" small center hole, the punch halves bolt
Note: Hole saws up to 1-1/8" diameter use 1/2"-20 thread, larger hole saws use together to cut and flare at the same time.
5/8"-18 thread.
ALL11070 ...... 1-1/2" Dia.
ALL11072 ...... 1-3/4" Dia.
ALL11074 ...... 2" Dia.
Digital Levels ALL11075 ...... 2-1/2" Dia. Sample Punch and Flare
ALL11076 ...... 2-5/8" Dia.
Digital level with magnetic ALL11078 ...... 3" Dia.
base measures the angle of
a single straight surface or Tin Snips
the angle of a joint between two straight
surfaces. Displayed value on the LCD screen Durable tin snips have offset blades to keep
rotates to right side up when digital level is in hands clear of metal while cutting. Non-slip
an upside down position. Powered by three jaws cut through sheet aluminum and up to 18 gauge low
3V CR2032 batteries (included). carbon steel. Blade length 1-1/4", total tool length 9-1/4".
ALL11030 ...... Red, Left Hand
ALL10742 ...... Compact Digital Level, 2" x 2" x 1"
ALL10744 ..... Digital Level, 6" x 2.25" x 1.25" ALL11031 ...... Green, Right Hand
Deburring Tool ALL11036
A fast and easy way to remove
burrs from the edges of
machined or cut metals. Five-
piece kit includes handle, telescopic
blade holder and three unique blades. Handle has built-in
storage for blades. Blade holder adjusts from 1" to 5".
