Body Radius Tool ALL23100 Fabrication Pencils
Solid oak tool can be used to flare Pencil works well
edges of wheel openings when fabri- for marking lines
cating fenders and quarter panels out of during metal
aluminum. Tool has two different radiuses to layout and fabrication.
create the correct flare for your needs. Multiple uses include marking steel tubing for cutting or
notching and marking patterns on painted aluminum or TOOLS & PIT EQUIPMENT
Sheet Metal Shrinker Stretcher Combo steel sheet metal. Silver reflective marks work best against
darker surfaces during cutting or welding for high visibility.
Make smooth radius curves and contours with Allstar’s Pencil marks are resistant to torch flames and will not burn
shrinker/stretcher combo. Shrinker or rub off.
creates inside curves and stretcher
expands for outside curves. ALL12064 ..... Pencil, 3-Pack
Each completely assembled tool ALL12066 ..... Mechanical Pencil, With Six Refills
includes a handle and mounting
hardware for securing Step Drill Sets
to a workbench. Tools Drill multiple size holes with one bit.
are capable of forming 18 Drill sheet metal and aluminum without
gauge mild steel, 16 gauge alu- deforming or distorting. Bits start on
minum and 20 gauge stainless. Kit is great contact, deburr, and chamfer while ALL11041
for forming fenders, radiator shrouds, or drilling, and do not require a center punch. Titanium
any item needing a smooth radius curve. nitride coated high speed steel. 1/4" shank.
ALL11023 ...... 1 Base With Two Jaws ALL11040 (3-Piece Set)
ALL11024 ...... 2 Bases With Two Jaws Drill Bit Sizes
Six Step 3/16", 1/4", 5/16", 3/8", 7/16", 1/2"
Nine Step 1/4", 5/16", 3/8", 7/16", 1/2", 9/16", 5/8", 11/16", 3/4"
Spring Steel Drill Bit ALL23115 1/8", 5/32", 3/16", 7/32", 1/4", 9/32", 5/16", 11/32",
Specially hardened drill bit is required Thirteen Step 3/8", 13/32", 7/16", 15/32", 1/2"
for drilling spring steel. The
17/64" size simplifies installa- ALL11041 (2-Piece Set)
tion of 1/4" hardware. Sold each. Drill Bit Sizes
Eleven Step 1/4", 25/64", 35/64", 11/16", 13/16", 7/8", 1", 1-1/8",
1-7/32", 1-1/4", 1-3/8"
Hammer Type Twelve Step 3/16", 1/4", 5/16", 3/8", 7/16", 1/2", 9/16", 5/8",
Spring Steel Punch ALL23116 11/16", 3/4", 13/16", 7/8"
Hammer type punch places a 1/4" diameter 3/16" Drill Bit
hole 1/2" from the end of most 1" x .062" thick
spring steel material. Punch features a built-in stop which Stop Collar ALL18217
positions the material for accurate hole placement. Punch Drill holes to specific depths
needs to be placed on a hard surface (i.e. concrete floor, quickly and easily. Steel collar
steel anvil, etc.) and struck lightly with a 3- to 4-lb. hammer. with Allen set screw locks onto bit for a positive hold.
Sold each.
Replacement Parts
ALL99013 ..... Mandrel For ALL23116
Double Ended Drill Bits
Impact Gun Double ended bits are basically
two bits in one. Convenient
Spring Steel Punch ALL23117
bit can be flipped around for
Impact gun style punch places a 1/4" a fresh sharp bit when drilling panels
diameter hole 1/2" from the end of most for Cleco fasteners or rivets. Package of 6.
1" x .062" thick spring steel material. Punch ALL18201 ..... 1/8"
features a built-in stop which positions the material for ALL18204 ..... 3/16"
accurate hole placement. Punch may be placed in a vice
or handheld and impact gun driven using a 3/4" socket. Drill Bit For Flange Rivets 13/64"
Replacement Parts ALL18203
ALL99014 ..... Mandrel For ALL23117 A common size bit for working
ALL99173 ..... Mandrel Bolt with 3/16" flange type rivets.
ALL99174 ..... Top Plate
High speed steel bits have black oxide finishes and self-
centering tips. Flute length: 1-3/16", overall length: 2-1/4".
43/64" Wheel Stud Drill Bit ALL11045
Package of 2.
43/64" bit is correct for drilling hubs or axle flanges to
accept most 5/8" wheel studs with
.690" knurl diameter. 1/2" shank.
