Chief Architect X10 Reference Manual

• Click the Color bar to select a color for • W h e n Use Backdrop is checked, the
the semi-transparent surfaces and lines in backdrop image specified for this view is
a Glass House view. See “Color Chooser/ used. When unchecked, the specified
Select Color Dialog” on page 203. Backdrop Color is used instead. See “3D
• Specify the Transparency of the surfaces Backdrops” on page 1159.
in Glass House view. For example, to cre- • Click Reset to Defaults to apply the
ate a wireframe line drawing of your Glass House settings defined in the
structure, turn transparency to full and Rendering Technique Defaults dialog.
minimize line thickness. • I n t h e Rendering Technique Defaults
• Specify the Line Thickness of surface dialog, the Restore Initial Settings but-
lines in Glass House view. ton is available instead. Click this to reset
the options on this panel to the originally
installed settings.

Duotone Panel
The active 3D view immediately the Rendering Technique Options settings for
updates to reflect any changes made to Duotone renderings.

1112
