Terrain Specification Dialog



                                                                       The settings on this panel are available for a
                                     Primary  and  secondary  contour  line  variety of other objects in the program. For
                                     labels  use  the  Text  Style  assigned  to  information about these settings, see “Line
                                their respective layers.  See “Text  Styles” on  Panel” on page 300.
                                page 519.
                                4   Specify the Label Units used by           Selected Arc Panel
                                    contour labels. Select either Inches or   The SELECTED ARC panel is available when
                               Decimal Feet (Millimeters or Meters for   the selected segment of the polyline is an arc
                               metric).
                                                                       as opposed to a line. See “Change Line/Arc”
                                                                       on page 260.
                                         Polyline Panel
                                                                       The settings on this panel are available for a
                               The POLYLINE panel states the length of the   variety of other objects in the program. For
                               Terrain Perimeter’s Perimeter, its enclosed   information about these settings, see “Arc
                               Area, and its Volume.                   Panel” on page 309.
                               The settings on the this panel are available
                               for a variety of other objects in the program.   Line Style Panel
                               For information about these settings, see   The settings on the LINE STYLE panel are
                               “Polyline Panel” on page 314.
                                                                       available for a variety of other objects in the
                                                                       program. For information about these
                                          Spline Panel                 settings, see “Line Style Panel” on page 301.
                               The SPLINE panel has a single option and is
                               only available if the Terrain Perimeter has       Fill Style Panel
                               been converted to a spline.  See “Convert to   The settings on the FILL STYLE panel affect
                               Spline” on page 263.
                                                                       the appearance of the Terrain Perimeter in
                                                                       floor plan view. For information about these
                                                                       settings, see “Fill Style Panel” on page 315.

                               New Segment Angle - Specify the angle            Materials Panel
                               between line segments that are used to draw
                               the spline. Specifying a smaller angle makes   The settings on the MATERIALS panel let you
                               the spline’s curvature smoother. Specify a   specify the terrain surface and terrain skirt
                               larger angle to draw the spline faster.  materials used in 3D views. These materials
                                                                       are not calculated in the Materials List. See
                                      Selected Line Panel              “Materials Panel” on page 1017.

                               The SELECTED LINE panel is available when          Label Panel
                               the selected edge of the Terrain Perimeter is a
                               line as opposed to an arc. See “Selected   The Terrain Perimeter label displays in floor
                               Edge” on page 214.                      plan and cross section/elevation views when
                                                                       the “Terrain Labels” layer is turned on and



                                                                                                      1219
