Chief Architect X10 Reference Manual

Polyline Panel The settings on this panel are available for a
variety of other objects in the program. For
The POLYLINE panel states the Length of an information about these settings, see “Line
open polyline or the Perimeter of a closed Panel” on page 300.
polyline. If multiple Elevation Line/Spline
segments form a closed Elevation Region, its Selected Arc Panel
Area will be calculated. Elevation Lines/
Splines do not have a thickness, so they have The SELECTED ARC panel is available when
no Volume. the selected object or segment is an arc as
opposed to a line.
Spline Panel
The settings on this panel are available for a
The SPLINE panel has a single option and is variety of other objects in the program. For
only available when the selected object is an information about these settings, see “Arc
elevation spline. See “Splines” on page 321. Panel” on page 309.
Line Style Panel

The settings on the LINE STYLE panel are
New Segment Angle - Specify the angle available for a variety of other objects in the
between line segments that are used to draw program. For information about these
the spline. Specifying a smaller angle makes settings, see “Line Style Panel” on page 301.
the spline smoother. Specify a larger angle to
draw the spline faster.
Label Panel
Selected Line Panel Elevation Line, Polyline, and Region labels
displays in floor plan view when the “Terrain
The SELECTED LINE panel is available when Labels” layer is turned on and use the Text
the selected object or segment is a line as Style assigned to that layer. See “Terrain and
opposed to one that has been converted to an Road Labels” on page 1214.
arc. See “Selected Edge” on page 214.
For more information, see “Label Panel” on
page 682.

Flat Region Specification Dialog

To open the Flat Region the Select Objects tool. See “Flat
Specification dialog, select a Flat Regions” on page 1208.
Region and click the Open Object edit
button, or double-click a Flat Region using The options in the Flat Region Specification
dialog are similar to those a number of other
dialogs in the program.

1222
