Garden Bed Specification Dialog

Selected Arc Panel plan view. For information about these
settings, see “Fill Style Panel” on page 315.
The SELECTED ARC panel is available when
the selected segment of the polyline is an arc Materials Panel
as opposed to a line. See “Change Line/Arc”
on page 260. The settings on the MATERIALS panel affect
the appearance of the selected object in 3D
The settings on this panel are available for a views. See “Materials Panel” on page 1017.
variety of other objects in the program. For
information about these settings, see “Arc
Panel” on page 309. Label Panel
Terrain Feature labels display in floor plan
Line Style Panel and cross section/elevation views when the
“Terrain Labels” layer is turned on and use
The settings on the LINE STYLE panel are the Text Style assigned to that layer. See
available for a variety of other objects in the “Terrain and Road Labels” on page 1214.
program. For information about these
settings, see “Line Style Panel” on page 301. For more information, see “Label Panel” on
page 682.
Fill Style Panel

The settings on the FILL STYLE panel affect
the appearance of the selected object in floor

Garden Bed Specification Dialog

To open the Garden Bed essentially the same as those in the Terrain
Specification dialog, select a Garden Feature Specification dialog. See “Terrain
Bed or group of Garden Beds and click the Feature Specification Dialog” on page 1225.
Open Object edit button or double-click the
Garden Beds also include the Distributed
Garden Bed(s) using the Select Objects Objects panel found in the Distribution
tool. Region Specification dialog. See
“Distribution Region/Path Specification
Because a Garden Bed is a type of Terrain
Feature, the settings in this dialog are Dialogs” on page 1004.

Terrain Break Specification Dialog

To open the Terrain Break the Terrain Break(s) using the Select Objects
Specification dialog, select a Terrain tool. See “Terrain Breaks” on page 1206.
Break or group of Terrain Breaks and click
the Open Object edit button or double-click

1227
