Raised / Lowered Region Specification Dialog

Fill Style Panel Label Panel
The settings on the FILL STYLE panel affect Hill and Valley labels display in floor plan
the appearance of the selected object in floor view when the “Terrain Labels” layer is
plan view. For information about these turned on and use the Text Style assigned to
settings, see “Fill Style Panel” on page 315. that layer. See “Terrain and Road Labels” on
page 1214.
For more information, see “Label Panel” on
page 682.

Raised / Lowered Region Specification Dialog

To open the Raised/Lowered Region The Raised / Lowered Region
Specification dialog, select one or Specification dialog is similar to the Hill /
more raised or lowered regions and click the Valley Specification dialog. See “Hill /
Open Object edit button, or double-click the Valley Specification Dialog” on page 1224.
region(s) using the Select Objects tool.

Terrain Feature Specification Dialog

To open the Terrain Feature program, including Water Features and
Specification dialog, select a Terrain Stepping Stones.
Feature or group of Terrain Features and Garden Beds are also a type of Terrain
click the Open Object edit button, or dou- Feature and have an additional Distributed
ble-click the Terrain Feature(s) using the
Plant panel in their specification dialog.
Select Objects tool. Garden Beds also have a preview pane on the
right side of their specification dialog.
Most of the panels in this dialog are similar
to those for a variety of other objects in the
