Chief Architect X10 Reference Manual

General Panel Selected Line Panel
The SELECTED LINE panel is available when
the selected edge of the polyline is a line as
opposed to an arc. See “Selected Edge” on
page 214.
Moving the Start of a line segment moves the
end of the previous connected line, if there is
• Define the Transition Distance, which is one. Similarly, moving the End of a line
the distance from the edge of the terrain segment moves move the start of the next
break to where the break stops affecting connected line, if there is one.
the terrain.
This panel is similar to the LINE panel of the
Polyline Panel Line Specification dialog. See “Line Panel”
on page 300.
The POLYLINE panel states the Length of an
open polyline or the Perimeter of a closed Selected Arc Panel
polyline. If multiple Terrain Break segments
form a closed polyline, its Area will be The SELECTED ARC panel is available when
calculated. Terrain Breaks do not have a the selected segment of the polyline is an arc
thickness, so they have no Volume. See as opposed to a line.
“Polyline Panel” on page 314. This panel is similar to the ARC panel of the
Arc Specification dialog. See “Arc Panel”
Spline Panel on page 309.

The SPLINE panel has a single option and is
only available when the selected object was Line Style Panel
converted to a Terrain Break from a spline. For information about the LINE STYLE panel,
See “Splines” on page 321. see “Line Style Panel” on page 301.

Fill Style Panel

New Segment Angle - Specify the angle The FILL STYLE panel is only available when
between line segments that are used to draw multiple Terrain Break segments enclose an
the spline. Specifying a smaller angle makes area. The settings on this panel affect the
the spline smoother. Specify a larger angle to appearance of the closed shape in floor paln
draw the spline faster. view. For more information, see “Fill Style
Panel” on page 315.

1228
