Chief Architect X10 Reference Manual

• Changes to the layer set used by the lay- are retained with the view and are not
out view. See “Layout View Layers” on affected when you switch to different
page 1296. defaults in the plan. See “Using Active
Defaults” on page 94.
In order for a view to be Dynamic, it must be
sent to layout using either the Entire Plan/ • The layer set used by a layout view does
View or Current View Send Option. In not change if you switch layer sets in the
addition, camera views must have Update plan. See “Layout Layer Sets” on page
Always specified. See “Send To Layout 198.
Dialog” on page 1291. Although changes in the plan do not affect a

When a floor plan view has been sent to layout view’s floor level, its Reference
layout, a few elements are Static and Display setting, or its Active Defaults, you
unaffected by changes in the plan: can specify all of these in the view’s Layout
Box Specification dialog. See “Plan View
• The default Display in Plan View setting Panel” on page 1301.
for pony walls becomes a permanent part
of the layout view. See “Pony Walls” on You can also change the layer set used by a
page 351. layout view using the Layout Box
• The floor level shown in a view sent to Layers edit tool. See “Layout View
layout does not change if you move to a Layers” on page 1296.
different floor in the plan. See “Multiple
Floors” on page 713. For information about controlling the display
of dynamic views in layout, see “Displaying
• The Reference Display setting in a Layout Views” on page 1296.
view sent to layout is unaffected if the
Reference Display is turned on or off in Semi-Dynamic Views
the plan. See “Reference Floor Display” Camera views, overviews, and cross section/
on page 722.
elevation views can all be sent to layout as
• The Color setting in a view sent to Semi-Dynamic views. Semi-Dynamic views
layout is unaffected if Color is toggled on reference the original view in the plan but no
or off in the original view unless that information about the model or the view’s
change is saved as one of the view’s layer settings update unless you prompt the
attributes. See “Saved Views” on page layout view to update.
154. When a cross section/elevation view has
been sent to layout, CAD objects, text, and
• The Rotate Plan View angle
becomes a permanent part of the layout dimensions in that view are fully Dynamic -
view. See “Rotate Plan View” on page even if the view is set to Update on
155. Demand. See “Detailing Cross Section/Ele-
vation Views” on page 1055.
• The Active Defaults that are in use In order for a view to be Semi-Dynamic, it
when a floor plan view is sent to layout must be sent using either the Entire Plan/

1294
