Corner Board Specification Dialog

lengthened or shortened using the edit The default material for corner boards is
handles. Corner boards can be copied, defined by the Exterior Trim entry in the
deleted and resized similar to other objects Material Defaults dialog. See “Material
using the edit toolbar or the Corner Board Defaults” on page 1013.
Specification dialog.

Corner Board Specification Dialog

Select one or more corner boards and The settings in this dialog are similar to those
click the Open Object edit button to in the Corner Board Defaults dialog, but
open the Corner Board Specification affect the selected corner boards rather than
dialog. all subsequently created corner boards.
General Panel

Specify the Width and Thickness of the Auto Place Corner Boards t o o l i s
selected corner board(s).
used. When unchecked, only outside cor-
Check Set Top/Set Bottom to specify the top ners receive corner boards.
and bottom heights of the corner board(s).
Inside Corner
•If Set Top is unchecked, the top of the
corner board automatically extends to the
top plate.
•If Set Bottom is unchecked, the bottom of
the corner board automatically extends to
the bottom of the floor platform.
In the Corner Board Defaults dialog, an Outside Corners
additional Auto Place Option is available.
• Check Include Inside Corners to place
Corner Boards on inside corners when the

901
