Chief Architect X10 Reference Manual

“Roof Returns and Other Details” on page • When this box is checked, the selected
828. roof trim is updated whenever you rebuild
the roof.
An Automatically Generated checkbox will
be present if a ridge cap, frieze molding, or • If the selected object is edited, this box
shadow boards polyline is selected. This will become permanently unchecked. To
checkbox is for reference only and cannot be restore the automatic updating behavior,
edited. See “Roof Returns and Other Details” the frieze, shadow boards, or ridge caps
on page 828. must be deleted and regenerated.

Selected Line Panel
The SELECTED LINE panel is available when • Length specifies the 3D length of the
the selected segment of the 3D molding selected edge of the 3D molding polyline.
polyline is a line as opposed to an arc. • Angle in XY Plane specifies the counter-
Most of the settings on this panel are the clockwise angle that the selected line
same as those on the LINE panel of the Line makes with the positive X axis when
Specification dialog. See “Line Panel” on viewed from above, as in plan view.
page 300. • Angle from XY Plane specifies the angle
The Length/Angle settings in the 3D that the selected line makes with the hori-
Molding Polyline Specification dialog are zontal XY plane when viewed from the
unique to this dialog. side, as in a cross section/elevation view.
A positive value means that the line
slopes up; a negative value means that it
slopes down.

Selected Arc Panel

The SELECTED ARC panel is available when Numerous other specification dialogs in the
the selected segment of the 3D molding program have a SELECTED ARC panel as
polyline is an arc as opposed to a line. well; however, most of the settings on this
panel work differently for 3D Molding
Polylines than they do for other objects.

916
