Chief Architect X10 Reference Manual

Molding Polylines are also deleted when the
Delete Objects dialog is used to delete CAD
objects. See “Deleting Objects” on page 283.

Molding Polyline Specification Dialog

To open the Molding Polyline information, see “Line Style Panel” on page
Specification dialog, select a molding 301.
polyline or group of molding polylines and
click the Open Object edit button. Selected Arc Panel

General Panel The SELECTED ARC panel displays when the
selected segment of the molding polyline is
an arc, as opposed to a line. See “Arc Panel”
on page 309.
Moldings Panel

The MOLDINGS panel can be found in dialogs
throughout the program. See “Moldings
Panel” on page 908.
One setting on this panel is unique to the
Molding Polyline and 3D Molding Polyline
• Specify the Molding Polyline’s Height, Specification dialogs:
relative to 0. • Check Inside to extrude the molding pro-
• Check No Molding on Selected Edge to file on the inside of closed polyline or
create blank section in the molding poly- right side of an open polyline.
line along the selected line segment.

Polyline Panel
The POLYLINE panel states the Length of an
open molding polyline, and the Perimeter
and Area of a closed molding polyline. See
“Polyline Panel” on page 314.
Molding extruded inside
Selected Line Panel • When unchecked, the molding profile
The SELECTED LINE panel is available when extrudes on the outside or left side of the
the selected segment of the molding polyline polyline.
is a line, as opposed to an arc. For more

914
